Lantronix LM-Series LM83X FIPS Certified 32-Port Console Server
Lantronix

Lantronix LM-Series LM83X FIPS Certified 32-Port Console Server

Console Server, 32 total serial ports, 1 USB-C, 1 USB 2.0, 2 GbE RJ45 Ethernet, 1 GbE SFP, FIPS 140-2 Level 2, Dual AC power, TAA

SKU
83X-32S-111-YAA
Category
Terminal & Device Servers

MSRP$5,700.00

$4,829.74

Save 15%
Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Lantronix through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
83X-32S-111-YAA
Category
Terminal & Device Servers

Overview

• The Lantronix LM-Series are console servers that also serve as a platform for network management automation.

• Managed devices are monitored over the console port at a default of every 30 seconds, providing data for rules-based decision-making and device remediation.

• Modular design to deploy what you need at each location, up to 104 ports in one rack unit: RJ-45 serial or Ethernet. Modem options include cellular, POTS line, fiber, even satellite links for out-of-band access anywhere on the planet.

• Virtual ports and port forwarding let you use the out-of-band platform as a resilient toolbox for secure access to all your network infrastructure.

• FIPS 142-2 Level 2 certification available.

Highlights

  • AI-driven out-of-band management: A patented expert system that uses rules-based AI to simplify out-of-band management plus recover and mitigate network infrastructure securely, reliably, and automatically.
  • Automated IPSLA tests provide data for triage and isolation of issues in the network within seconds
  • The LM-Series can alarm, but also take automated recovery actions just like an admin. Some examples include clearing an interface, cycling power, even recognizing and recovering a router in ROMmon state.
  • Monitor, diagnose AND TAKE ACTION with automated capabilities; resolve problems in minutes vs. hours or days, automate the tedious and error prone manual tasks
  • Reduce OPEX & truck rolls and increase uptime & visibility

Specifications

Package Contents
  • 32-Port LM83X- FIPS Certified
  • 2 x Power Cords
  • 2 x Rack Mount Ears
  • 4 x Mounting Screws
  • 1 x USB-A to USB-C cable
  • 1 x Connection Instruction Sheet
  • 1 x Warranty Booklet
  • LMS
Product TypeDevice Server
Input Voltage120 V AC, 230 V AC
Manufacturer Part Number83X-32S-111-YAA
Limited Warranty1 Year
Standard Memory250 GB
Weight (Approximate)8.20 lb
Form FactorRack-mountable
ManufacturerLantronix, Inc
Product ModelLM83X
Product NameLantronix 32-Port LM83X - FIPS Certified
Power Consumption60 W
Product SeriesLM
Brand NameLantronix
Input Voltage Range100 - 240 VAC
Country of OriginUnited States
Height1.7"
Width17.5"
Depth10.4"
Network Standard10/100/1000Base-T
Environmentally FriendlyYes
Ethernet TechnologyGigabit Ethernet
USBYes
Number of Network (RJ-45) Ports3
Network (RJ-45)Yes
Number of USB Ports2
Serial PortYes
Management PortYes
Media Type SupportedTwisted Pair
Number of Serial Ports32
Total Number of Expansion Slots3
TAA CompliantYes
Environmental ComplianceChina Restriction of Hazardous Substances (China RoHS), Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE)
