GVision R22ZD-OB-45P0 22" Class Open-frame LCD Touchscreen Monitor - 16:9 - 5 ms
GVision

GVision R22ZD-OB-45P0 22" Class Open-frame LCD Touchscreen Monitor - 16:9 - 5 ms

22" Viewable - Projected Capacitive - Multi-touch Screen - 1280 x 1024 - SXGA - 16.7 Million Colors - 1,000:1 - 250 Nit - LED Backlight - USB - VGA - Black

SKU
R22ZD-OB-45P0
Category
Touchscreen Monitors

MSRP$652.00

$475.32

Save 27%
Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine GVision through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
R22ZD-OB-45P0
Category
Touchscreen Monitors

Overview

GVision's line of rear mount projected capacitive displays are purpose built for system builders who require a rugged and durable touch screen solution that can easily be integrated into any embedded application. Flexibile mounting options makes it easy to mount the product into a custom enclosure. The touch screen is completely sealed to protect against the elements, which means it can be used either inside or out, and in high-traffice public facing applications.

Highlights

  • The open-frame lcd touchscreen monitor is ideal for clubhouse gaming, entertainment, and self-service kiosks with reliable touchscreen performance
  • SXGA touchscreen offers SXGA resolution up to 1280 x 1024 pixels for sharp, detailed visuals ideal for office and industrial use
  • Projective Capacitive technology allows touch with bare fingers or thin gloves for flexibility in medical and industrial use
  • LED backlight technology reduces power use and hazardous materials for eco-friendly performance
  • Captivating visuals with about 250 Nit brightness levels for clear and vivid touchscreen performance
  • The 1,000:1 contrast ratio delivers deep blacks and bright whites for cinematic touchscreen visuals
  • 16.7 million colors supported for lifelike visuals and smooth touch-based creative workflows
  • VESA mount compatibility allows flexible installation on walls or stands to suit your workspace needs

Specifications

Aspect Ratio16:9
Product TypeOpen-frame LCD Touchscreen Monitor
Contrast Ratio1,000:1
Manufacturer Part NumberR22ZD-OB-45P0
Response Time5 ms
Touchscreen TypeProjected Capacitive
Brightness250 Nit
Color Supported16.7 Million Colors
ManufacturerGVision, Inc
Product ModelR22ZD-OB-45P0
Product Name22" Rear Mount Projected Capacitive Touch Screen Monitor
Mount TypeRear Mount
Viewable Screen Size22"
Maximum Resolution1280 x 1024
Brand NameGVision
Screen ModeSXGA
Height13.4"
Width21.6"
Depth1.9"
USBYes
Backlight TechnologyLED
VESA Mount CompatibleYes
Operating Power Consumption18 W
VGAYes
Multi-touch ScreenYes
Screen Size Class22"
Product ColorBlack
