Genuine Grandstream Networks through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
GWN7602
Category
Wireless Access Points/Bridges
Overview
The GWN7602 is a compact Wi-Fi access point designed for small businesses, homes, offices, hotels and more. It provides three 100Mb ports to provide IP phones, IPTV, computers and similar devices with ethernet while also providing an uplink Gigabit network port with PoE/PoE+ and PSE. The GWN7602 offers dual band 2x2:2 MIMO technology and a sophisticated antenna design for ideal network throughput that supports up to 80 clients and a 100 meter coverage range. To ensure easy installation and management, the GWN7602 is supported by GWN.Cloud, Grandstream's free cloud Wi-Fi management platform. The GWN7602 is the ideal Wi-Fi AP for voice-over-Wi-Fi deployments and offers a seamless connection with Grandstream's Wi-Fi-capable voice and video IP phones. By including support for advanced QoS, lowlatency real-time applications, mesh networks and captive portals, the GWN7602 is a wireless access point built for deployment scenarios with small to medium user density.
Highlights
Wireless Access Point offers maximum wireless connection efficiency and convenience
1.17 Gbit/s wireless transmission speed provides high and efficient communication with maximum efficiency
Ensure speedy data transfer of up to 1.17 Gbit/s with the IEEE 802.11ac wireless technology
Link your Wi-Fi traffic to your wired network with Fast Ethernet port
Electrical power is transmitted along with the data in a single cable to devices such as the Access Points, IP cameras or IP phones
Wall Mountable form factor for your usage convenience and better reliance
Specifications
Package Contents
Wi-Fi AP with Integrated Ethernet Switch
Quick Start Guide
Product Type
Wireless Access Point
Manufacturer Part Number
GWN7602
Weight (Approximate)
6.63 oz
Form Factor
Wall Mountable
Manufacturer
Grandstream Networks, Inc
Product Model
GWN7602
Product Name
Wi-Fi AP with Integrated Ethernet Switch
Wireless Transmission Speed
1.17 Gbit/s
Brand Name
Grandstream
Country of Origin
China
Height
5.3"
Width
4.5"
Depth
1.2"
Frequency Band
2.40 GHz, 5 GHz
Environmentally Friendly
Yes
Wireless LAN Standard
IEEE 802.11ac
Ethernet Technology
Fast Ethernet, Gigabit Ethernet
Number of Network (RJ-45) Ports
4
PoE (RJ-45) Port
Yes
Total Number of Antennas
2
Number of Internal Antennas
2
MIMO Technology
Yes
PoE PD Port
Yes
Environmental Compliance
Waste Electrical and Electronic Equipment Directive (WEEE), China Restriction of Hazardous Substances (China RoHS)
