Eaton Tripp Lite Series USB-C Docking Station for Steam Deck and ROG Ally - 4K 60 Hz HDMI, USB Hub, Gigabit Ethernet, 100W PD Charging
for Monitor, HDTV, Video Game System, Keyboard, Mouse, Hard Drive, Desktop PC, Flash Drive, Gaming Console - Charging Capability - USB Type C - 1 Displays Supported - 4K @ 60Hz, 4K - 3840 x 2160 - 4 x USB Ports - 2 x USB Type-A Ports - USB Type-A - 2 x USB Type-C Ports - USB Type-C - Network (RJ-45) - 1 x HDMI Ports - HDMI - Black - Wired - Gigabit Ethernet - 100W
- SKU
- U442-DOCKSD-1
- Category
- Docking Stations
MSRP$117.06
$47.93
Save 59%In stock: 291
Genuine Eaton through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- U442-DOCKSD-1
- Category
- Docking Stations
Overview
Features | USB-C Docking Station Turns Your Handheld Gaming Console into a Desktop Gaming PC
This USB-C dock with PD charging expands the potential of your Steam Deck or ASUS ROG Ally. Just insert your game console into the docking station's cradle, and connect the dock's built-in USB-C cable to your handheld's USB-C port. You can now experience handheld gaming on a large 4K screen, connect a keyboard and mouse, transfer data to external storage, join a wired Gigabit Ethernet network and charge your gaming console to maximum power.
Transmits 4K Video with HDR and 4:4:4 Color
The HDMI port supports Ultra HD 4K resolutions up to 3840 x 2160 at 60 Hz with 36-bit Deep Color for gameplay on a large monitor. The U442-DOCKSD-1 supports HDR (High Dynamic Range), providing a wide range of vibrant colors with richer contrast, brighter whites and deeper blacks that pop on your 4K display. This dock also supports uncompressed 4:4:4 chroma subsampling for top-level PC gaming.
PD Charging Port Supports up to 100W for Rapid Syncing and Charging
The Power Delivery port provides power output up to 20V 5A (100W), which is sufficient for fast-charging your Steam Deck or ROG Ally when not in use. Connect a user-provided USB-C charging cable (sold separately) between the USB-C PD charging port and a compatible USB-C PD charger.
USB Ports Connect Keyboards, Thumb Drives and Other Peripherals
One USB-C and one USB-A hub port accept USB peripherals, such as external storage drives, mice and keyboards. They support USB 3.2 Gen 1 data transfer rates up to 5 Gbps (10 times faster than USB 2.0) and are backward compatible with USB 2.0 and USB 1.1 devices.
Accesses a Wired Gigabit Ethernet Network
The RJ45 port offers access to a Gigabit Ethernet network when Wi-Fi is unavailable or when a wired connection offers faster speeds. Connect using a UTP cable (sold separately), and enjoy true 10/100/1000 Mbps Ethernet speeds for fast lag-free gaming.
Ready to Use Right Out of the Package
The plug-and-play USB-C dock is specifically designed for use with the Smart Deck or ROG Ally. It requires no extra software to be downloaded and installed.
Warranty
Limited Warranty: 3 Year
About Eaton
Eaton is an intelligent power management company dedicated to improving the quality of life and protecting the environment for people everywhere. We are guided by our commitment to do business right, to operate sustainably and to help our customers manage power ─ today and well into the future. By capitalizing on the global growth trends of electrification and digitalization, we're accelerating the planet's transition to renewable energy and helping to solve the world's most urgent power management challenges.
Highlights
- Connects Steam Deck or ROG Ally to a large-screen display for more immersive gaming
- HDMI port supports 4K @ 60 Hz with HDR, 4:4:4 chroma and 36-bit Deep Color
- USB-A and USB-C ports reach speeds up to 5 Gbps for storage drives or keyboard/mouse
- RJ45 port allows wired access to a Gigabit Ethernet network for online gaming
- Power Delivery port supports 20V 5A (100W) power output for charging game device
- 3-year limited warranty
Specifications
| Package Contents |
|
|---|---|
| Host Interface | USB Type C |
| Product Type | Docking Station |
| Device Supported | Monitor, HDTV, Video Game System, Keyboard, Mouse, Hard Drive, Desktop PC, Flash Drive, Gaming Console |
| Manufacturer Part Number | U442-DOCKSD-1 |
| Limited Warranty | 3 Year |
| Weight (Approximate) | 4.64 oz |
| Connectivity Technology | Wired |
| Manufacturer | Eaton Corporation |
| Product Model | U442-DOCKSD-1 |
| Product Name | U442-DOCKSD-1 Docking Station |
| Brand Name | Tripp Lite series |
| Charging Capability | Yes |
| Height | 1.16" |
| Width | 5.59" |
| Depth | 2.01" |
| Ethernet Technology | Gigabit Ethernet |
| HDMI | Yes |
| Number of HDMI Ports | 1 |
| Network (RJ-45) | Yes |
| Total Number of USB Ports | 4 |
| Number of Displays Supported | 1 |
| USB Type-C | Yes |
| USB Type-C Detail | 1 x USB-C: 0.9A, 1 x USB-C: 100W (20V 5A) Power Delivery |
| Number of USB Type-C Ports | 2 |
| Number of USB Type-A Ports | 2 |
| Product Color | Black |
| USB Power Delivery | 100W |
| Supported Resolutions | 3840 x 2160 |
| Number of USB 3.2 Gen 1 Type-A Ports | 2 |
| USB Type-A | Yes |
| Screen Mode Supported | 4K @ 60Hz, 4K |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH), Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE) |
