Eaton Tripp Lite Series 2x4 USB Peripheral Sharing Switch - USB 3.2 Gen 1 (5 Gbps), 2 USB-C Hosts, 4 USB-A Hub Ports
USB Type C - 640 MB/s - Notebook, Desktop, Printer, Keyboard, Mouse, Flash Drive, Hard Drive - Desktop - 6 USB Port(s)
- SKU
- U315-2X4
- Category
- USB/Firewire Adapters
MSRP$112.00
$45.85
Save 59%In stock: 62
Genuine Eaton through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- U315-2X4
- Category
- USB/Firewire Adapters
Overview
Features | Share 4 USB Devices Between 2 Computers at the Same Time
Share a USB printer, scanner, keyboard/mouse, flash drive, external hard drive or other USB peripherals between two computers, and save time, money and precious workspace. This USB switch eliminates the cost of buying multiple USB devices for each computer, as well as the headache of determining where to put them and their cables. All four USB-A hub ports support USB 3.2 Gen 1 data transfer rates up to 5 Gbps.
Switching Back and Forth Takes Just a Push of a Button
If you use more than one computer on a daily basis, whether you're working from home on one computer and playing the latest high-tech games on another, you can share peripherals on both. Just push the button on the front of the U315-2X4 to switch seamlessly between the two host computers. The compact switch takes up very little space on your desktop.
Host Cables Are Included
Connect the two USB-C host cables to the USB-C inputs on your computers. If you would rather use the USB-A inputs on one or both computers, each cable includes a built-in USB-A adapter. Note : An optional 3.5 mm power cable is also included. It is only necessary when the USB devices connected to the switch require more power than is available from the host's USB hub port.
Warranty
Limited Warranty: 1 Year
About Eaton
Eaton is an intelligent power management company dedicated to improving the quality of life and protecting the environment for people everywhere. We are guided by our commitment to do business right, to operate sustainably and to help our customers manage power ─ today and well into the future. By capitalizing on the global growth trends of electrification and digitalization, we're accelerating the planet's transition to renewable energy and helping to solve the world's most urgent power management challenges.
Highlights
- Switch between as many as 4 USB-A peripherals at the push of a button
- USB-A ports support USB 3.2 Gen 1 speeds up to 5 Gbps to ensure fast data transfers
- Included DC power cord provides optional extra power for high-power devices
- USB-C host cables with built-in USB-A adapters included for connecting to computers
- Plug-and-play operation with no software required for easy, immediate installation
- 1-year limited warranty
Specifications
| Application/Usage | Notebook, Desktop, Printer, Keyboard, Mouse, Flash Drive, Hard Drive |
|---|---|
| Package Contents |
|
| Host Interface | USB Type C |
| Product Type | USB Switch |
| Data Transfer Rate | 640 MB/s |
| Manufacturer Part Number | U315-2X4 |
| Limited Warranty | 1 Year |
| Weight (Approximate) | 12.32 oz |
| Features | Plug and Play |
| Form Factor | Desktop |
| Manufacturer | Eaton Corporation |
| Product Model | U315-2X4 |
| Product Name | U315-2X4 USB Switch |
| Brand Name | Tripp Lite series |
| Country of Origin | China |
| Height | 0.8" |
| Width | 3.7" |
| Depth | 2.1" |
| Total Number of USB Ports | 6 |
| UASP Support | No |
| USB Connector Type | Type-C, Type-A |
| TAA Compliant | No |
| USB Version | 3.2 Gen 1 |
| Product Color | Black |
| Color Family | Black |
| Product Material | Acrylonitrile Butadiene Styrene (ABS) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS), Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
