Broadcom MegaRAID 9460-8i SAS Controller
12Gb/s SAS - PCI Express 3.1 x8 - Plug-in Card - 4 x SFF-8643 - 8 Total SAS Port(s) - 8 SAS Port(s) Internal - PC - 2 GB
- SKU
- 05-50011-02
- Category
- SCSI/RAID Controllers
MSRP$2,974.16
$2,578.08
Save 13%Back ordered — ships when restocked.
Genuine Broadcom through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- 05-50011-02
- Category
- SCSI/RAID Controllers
Overview
Today's data center, cloud and high-performance computing environments not only require large amounts of storage capacity, they also must provide the data protection and performance that their applications and end users demand. The MegaRAID 9460-8i Tri-Mode Storage Adapter is a 12Gb/s SAS/SATA/PCIe (NVMe) controller card that addresses these needs by delivering proven flexibility, performance and RAID data protection for a range of server storage applications.
Broadcom's Tri-Mode SerDes Technology enables the operation of NVMe, SAS or SATA devices in a single drive bay, allowing for endless design flexibility.
• Connect up to 240 SAS/SATA devices or 24 NVMe devices per controller
• Fits into rack-mounted servers with low-profile form factor and side-mounted SAS connectors
• Support critical, high-bandwidth applications with PCIe ® 3.1 connectivity
• Balance protection and performance for critical applications with RAID levels 0, 1, 5, 6, 10, 50, and 60
• Add more protection and peace of mind with CacheVault ® flash cache protection
Specifications
| Host Interface | PCI Express 3.1 x8 |
|---|---|
| Product Type | SAS Controller |
| Manufacturer Part Number | 05-50011-02 |
| Platform Supported | PC |
| Form Factor | Plug-in Card |
| Manufacturer | Broadcom Corporation |
| Product Model | 9460-8i |
| Product Name | MegaRAID 9460-8i SAS Controller |
| Product Line | MegaRAID |
| Controller Type | 12Gb/s SAS |
| Brand Name | Broadcom |
| Height | 2.7" |
| Width | 6.1" |
| Total Number of SAS Ports | 8 |
| Number of SAS Ports (Internal) | 8 |
| SAS Connector Details | 4 x SFF-8643 |
| Cache Memory | 2 GB |
