16 Computer(s) - 1 Local User(s) - 4 Remote User(s) - 1920 x 1200 - 17 x Network (RJ-45) - 2 x USB - 1 x VGA - 1U - Rack-mountable, Desktop
MSRP$2,774.68
$2,287.67
Save 18%Special order — estimated available by September 10, 2026.
Genuine Black Box through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
Description
ServSwitch CX Quad IP
Quick Facts
• IP support enables you to access servers remotely.
• Connect up to four IP users, plus one local user, simultaneously.
• 1600 x 1200 maximum resolution, or up to 1920 x 1200 in half-width mode.
Further Details
• Simplify cabling with CAT5, CAT5e, or CAT6 UTP cable.
• Supports PC, Macintosh®, and Sun?.
• Connect PS/2 or USB supported servers/computers.
• Cascade switches to control up to 256 servers.
The ServSwitch CX Quad IP has all the features you're looking for to help manage your enterprise network. Like the ServSwitch CX with IP (KV1416A-R2, KV1424-R2), this model is compatible with all major computer platforms; connects via lightweight, inexpensive twisted-pair cable; and enables you to access servers across any IP network-even the Internet. The ServSwitch CX Quad IP supports up to four remote users over TCP/IP using VNC, plus a local user, for a total number of five users simultaneously.
Reaches as far as your network.
Access and switch remotely between servers over a private intranet or over the Internet. All you need is a Java® enabled Web browser. Password security keeps out unauthorized users.
It's secure, too.
Although the ServSwitch CX Quad IP can be installed behind the security of your network firewall, it also has the robust security features it needs to be safe on its own. Sophisticated 128-bit public/private key protection locks the switch tight against unauthorized access. Two-tier password protection-administrative and non-adminstrative-adds another layer of protection. You can also restrict client IP addresses, limit access to dialup connections only, or use non-standard port numbers to further confound would-be hackers.
Easier connections than ever!
There are no bulky KVM cables to deal with. Connect servers via lightweight and inexpensive CAT5, CAT5e, or CAT6 UTP cable.
The servers connect with UTP cable. At the server end, a Server Access Module (SAM) (sold separately) provides keyboard, video, and mouse connections. Servers may be placed up to 32 feet (9.8 m) from the switch.
Limited Warranty: 2 Year
For over forty years, Black Box has been a world-leading provider of premier IT infrastructure solutions. Today, we continue to design and manufacture award-winning products for Pro AV, KVM, cabling and networking known for their advanced functionality, flawless performance, outstanding reliability and fail-safe security. Our solutions are used every day in government, education, commercial enterprises and any other organization that requires the utmost quality and performance from their IT infrastructure. On top of creating industry-leading products, Black Box demonstrates every day a complete commitment to providing our customers with the best technical support and service in the industry. Our award-winning, dedicated support staff works around the clock to ensure our customers’ systems are always up and running optimally. They are truly as important to the successful IT, communications and business operations of our customers as the powerful products and solutions we deliver.
| General Information | |
|---|---|
| Manufacturer | Black Box Corporation |
| Manufacturer Part Number | KV4161A |
| Brand Name | Black Box |
| Product Line | ServerSwitch |
| Product Name | ServSwitch CX Quad IP |
| Packaged Quantity | 1 |
| Product Type | KVM Switchbox |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| USB | Yes |
| VGA | Yes |
| Number of Network (RJ-45) Ports | 17 |
| Number of USB Ports | 2 |
| Number of VGA Ports | 1 |
| Physical Characteristics | |
| Form Factor | Rack-mountable, Desktop |
| Rack Height | 1U |
| Height | 7.9" |
| Width | 4.8" |
| Depth | 1.8" |
| Technical Information | |
| KVM Technology | Digital |
| Number of Computers Supported | 16 |
| Number of Local Users Supported | 1 |
| Number of Remote Users Supported | 4 |
| Maximum Operating Distance | 984.20 ft |
| Video | |
| Graphic Mode | UXGA, WUXGA |
| Maximum Video Resolution | 1920 x 1200 |
| Warranty | |
| Limited Warranty | 2 Year |
| Miscellaneous | |
| Package Contents |
|
| Environmentally Friendly | Yes |
| Country of Origin | United Kingdom |
