SKU
CS1642A
Category
KVM Switchboxes
Overview
The CS1642A 2-Port USB DVI Dual View KVMP? Switch is a multi-application device that integrates a 2-port KVM switch with 2-port USB hub. The newest version now supports Quad-View functionality with two Dual View KVM Switches connected.
The new CS1642A features multi-view capabilities, which allow two switches to be daisy chained for a dual, triple, or quadview display across multi-monitor installations. The CS1642A supports advanced nVidia 3D Vision ready 120Hz 3D displaying,allowing you to manage various 3D visual effects. It allows you to manipulate all connected computers from a single console to save resources and work space. It enables each computer to access connected peripherals on a one-computer-at-a-time basis, making it ideal for users who need delicate visual effects and multi-tasking on several computers. The CS1642A is perfect for graphic designers, banking and financial consultants, gamers and medical professionals-demanding a high quality switch that provides stunning color, clarity and functionality.
More from the Manufacturer
Highlights
One dual-screen USB console controls two/four dual-screen computers and two additional USB devices
Multi-View Display - Easily connect two CS1642A/1644A's units for a second dual-screen setup controlled through a single connection
Superior video quality - 2560 x 1600 at 60Hz (DVI Dual link); and 3D displays up to 1920 x 1200 at 120Hz (DVI Single link)
Supports widescreen resolutions
Independent switching of KVM, USB, and Audio focus
DVI digital and analog monitor support - fully compliant with DVI specifications; and HDCP compliant
Multiplatform support - Windows 2000/XP/Vista, Linux , Mac, Sun,and FreeBSD
Sun/Mac keyboard support and emulation
Video DynaSync, exclusive ATEN technology, to eliminate boot-up display problems and optimizes resolution when switching between ports
Power on detection - if one computer is powered off, the CS1642A will automatically switch to the next powered-on computer
Specifications
Package Contents
2-Port USB DVI Dual View KVMP Switch
4 x Custom DVI Dual Link Cable Sets
1 x Power Adapter
1 x User Instructions
Product Type
KVM Switchbox
Manufacturer Part Number
CS1642A
Packaged Quantity
1
Weight (Approximate)
1.23 lb
Manufacturer
ATEN Technology, Inc
Product Model
CS1642A
Product Name
2-Port USB DVI Dual View KVMP Switch
Brand Name
ATEN
Height
1.8"
Width
3"
Depth
10.3"
Environmentally Friendly
Yes
Maximum Video Resolution
2560 x 1600
Graphic Mode
WQXGA
USB
Yes
DVI
Yes
Number of Network (RJ-45) Ports
1
Network (RJ-45)
Yes
Number of USB Ports
6
Number of DVI Ports
6
Number of Computers Supported
2
Number of Local Users Supported
1
Environmental Compliance
Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE)
