4 GB RAM DDR3L SDRAM - Gigabit Ethernet - 15" Active Matrix TFT LCD Touchscreen Display - Network (RJ-45) - 2 Total USB Port(s) - 1 USB 2.0 Port(s) - 1 USB 3.0 Port(s)
SKU
Category
Terminals/Thin Clients
$1,163.86
Back-ordered
Special order — estimated OEM lead time 3–8 weeks. Order today and we expect to receive stock between Oct 6 and Nov 10, then process your delivery right after.
Genuine Advantech through authorized distribution — NDAA §889 screened before checkout. TAA verified on request.
SKU
Category
Terminals/Thin Clients
Country of origin
Taiwan
Country of origin is manufacturer-reported and can vary by production lot. Where TAA applies to your purchase, we verify the shipping unit's origin on request.
Overview
The TPC-1551T thin-client terminal is equipped with a 15" XGA TFT LCD, low-power Intel® Atom E3827 1.75 GHz dual-core processor, and 4 GB DDR3L SDRAM to deliver highperformance computing in a compact, fanless system. For enhanced durability, TPC-1551T features a true-flat touchscreen with IP66-rated front panel, die cast aluminum alloy front bezel, and 5-wire resistive touch control. In addition to supporting a wide operating temperature range (-20 ~ 60 °C/-4 ~ 140 °F), TPC-1551T includes a full-size mini PCIe slot for extending the system functionalities to satisfy diverse automation application needs. Moreover, Advantech's iDoor technology can be integrated via the mini PCIe slot in order to provide additional I/O connectors, isolated digital I/O, fieldbus protocols, 3G/GPS/GPRS/Wi-Fi communication, and MRAM.
Highlights
Industrial-grade 15" XGA TFT LCD with 50K lifetime and LED backlight
Intel® Atom E3827 1.75 GHz dual-core processor with 4 GB DDR3L SDRAM
Wide operating temperature range -20 ~ 60 °C (-4 ~ 140 °F)
True-flat touchscreen with IP66-rated front panel/non-flat touchscreen with IP65-rated front panel
Front-facing LED indicators to show operating status
Durable touchscreen with 5-wire resistive touch control
Supports Advantech's iDoor technology for integrating optional accessories
Compact, fanless embedded system with aluminum alloy front bezel and chassis grounding protection
