Advantech IDS-3212R-45SVA1E 12" Class LCD Touchscreen Monitor - 4:3 - 35 ms
Advantech

Advantech IDS-3212R-45SVA1E 12" Class LCD Touchscreen Monitor - 4:3 - 35 ms

12.1" Viewable - 5-wire Resistive - 800 x 600 - SVGA - 16.2 Million Colors - 450 Nit - LED Backlight - DVI - USB - VGA - 2 Year

SKU
IDS-3212R-45SVA1E
Category
Touchscreen Monitors

$508.98

Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Advantech through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
IDS-3212R-45SVA1E
Category
Touchscreen Monitors

Overview

Introduction

The Advantech IDS-3212 Embedded Industrial Panel Mount Monitor series offers flexible options for LCD, touchscreen, signal interface and chassis mounting. The series with standard integrated frame design, supports rear and VESA mounting which brings the benefits of easy installation, and flexibility for different applications.

Highlights

  • 12.1" SVGA / XGA LCD panel with LED backlight for 20% power savings, and environmental protection
  • -20° C ~ +60° C wide range operating temperature
  • 5-wire resistive touch screen solution or 3mm tempered smudge resistant protected
  • Combo touch interface, both RS-232 and USB
  • Dual signal interface with VGA & DVI
  • Standard integrated frame
  • Versatile mounting method for rear mounting and VESA mounting
  • Anti-Reflective treatment (optional)
  • Ultra high brightness solution of 1200 cd/m2 for utdoor applications (optional)

Specifications

Aspect Ratio4:3
Package Contents
  • IDS-3212R-45SVA1E LCD Touchscreen Monitor
  • 1 x M Cable USB-A(M)/USB-A(M) 180CM
  • 1 x VGA cable 15P(M) 180 cm
  • 4 x Clampers
  • 4 x Screws of clamper M4_25L
  • 1 x Cable clamp
  • 1 x Screw of cable clamp
  • 1 x Cable tie
  • USB Cable
Product TypeLCD Touchscreen Monitor
Manufacturer Part NumberIDS-3212R-45SVA1E
Response Time35 ms
Limited Warranty2 Year
Touchscreen Type5-wire Resistive
Weight (Approximate)5.51 lb
Brightness450 Nit
Color Supported16.2 Million Colors
ManufacturerAdvantech Co., Ltd
Product ModelIDS-3212R-45SVA1E
Product NameIDS-3212R-45SVA1E LCD Touchscreen Monitor
Mount TypePanel Mount
Product SeriesIDS-3212R
Viewable Screen Size12.1"
Maximum Resolution800 x 600
Brand NameAdvantech
Screen ModeSVGA
Country of OriginTaiwan
Height10.3"
Width12.7"
Depth1.4"
Environmentally FriendlyYes
USBYes
Backlight TechnologyLED
VESA Mount CompatibleYes
VESA Mount Standard100 x 100
Operating Power Consumption36 W
Native Contrast Ratio700:1
DVIYes
VGAYes
Number of USB Ports1
Screen Size Class12"
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
