Advantech EKI-6333AC-2GD Dual Band Wi-Fi 5 IEEE 802.11 a/b/g/n/ac 1.14 Gbit/s Wireless Access Point
Advantech

Advantech EKI-6333AC-2GD Dual Band Wi-Fi 5 IEEE 802.11 a/b/g/n/ac 1.14 Gbit/s Wireless Access Point

2.40 GHz, 5 GHz - 2 x External Antenna(s) - External - MIMO Technology - 2 x Network (RJ-45) - Fast Ethernet, Ethernet, Gigabit Ethernet - 17 W - DIN Rail, Wall Mountable - IP30

SKU
EKI-6333AC-2GD-A
Category
Wireless Access Points/Bridges

$553.95

Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Advantech through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
EKI-6333AC-2GD-A
Category
Wireless Access Points/Bridges

Overview

The EKI-6333AC-2GD is a feature rich wireless Access Point with DIN-rail type design which provides a reliable connectivity for industrial environments. With the support of STP, WMM and IGMP snooping protocols, EKI-6333AC-2GD improves the reliability of wireless connectivity, especially in applications requiring high reliability and data throughput transmission. To secure the wireless connection, EKI-6333AC-2GD implements the latest encryption technologies, including WPA3/WPA2/WPA/802.1x for powerful security authentication.

Highlights

  • 802.11 a/b/g/n/ac MIMO 2x2, 2.4/5GHz dual band concurrent
  • WLAN transmission rates up to 1167 Mbps
  • Secure access with WEP, 802.1x, WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise
  • Provides Web-based configuration
  • Supports WAN and NAT for efficient network routing and address management
  • 2.4/5GHz wireless redundancy ensures reliable connectivity by switching bands during interference or failure

Specifications

Application/UsageIndustrial
Product TypeWireless Access Point
Manufacturer Part NumberEKI-6333AC-2GD-A
Limited Warranty24 Month
Weight (Approximate)1.23 lb
Network BandDual Band
Communication ProtocolsICMP, ARP, IPv4, IPv6, UDP, DHCP, Telnet, SNMP, HTTP, PPPoE, SSH, STP, IGMP
Form FactorDIN Rail, Wall Mountable
ManufacturerAdvantech Co., Ltd
Product ModelEKI-6333AC-2GD
Product NameEKI-6333AC-2GD Wireless Access Point
Power Consumption17 W
Wireless Transmission Speed1.14 Gbit/s
Brand NameAdvantech
Plug/Connector TypeTerminal Block
Height5.5"
Width1.2"
Depth4.4"
Frequency Band2.40 GHz, 5 GHz
Antenna Form FactorExternal
Wireless LAN StandardIEEE 802.11 a/b/g/n/ac
Encryption StandardWPA-Personal, WPA2-Personal, WPA-ENT, WPA2-ENT, WPA3, WPA2, WPA, WEP
Ethernet TechnologyFast Ethernet, Ethernet, Gigabit Ethernet
Number of Network (RJ-45) Ports2
Total Number of Antennas2
Number of External Antennas2
Data EncryptionYes
MIMO TechnologyYes
Ingress Protection (IP) RatingIP30
Wi-Fi GenerationWi-Fi 5
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
