Advantech DS-082 Ultra-slim 3/4 Display Digital Signage Player
Ryzen V1605B 2 GHz - 32 GB DDR4 SDRAM - 2160p - HDMI - USB - SerialEthernet - Windows 10, Linux
SKU
Category
Digital Signage Systems
$803.97
Back-ordered
Special order — estimated OEM lead time 3–8 weeks. Order today and we expect to receive stock between Oct 5 and Nov 9, then process your delivery right after.
Genuine Advantech through authorized distribution — NDAA §889 screened before checkout. TAA verified on request.
SKU
Category
Digital Signage Systems
Overview
Measuring at 19 mm thick, DS-082 is the world's slimmest digital signage player powered by AMD Ryzen V1000/R1000 series. This thin-andpowerful signage player is equipped with 4 x HDMI display which is capable to achieve up to 4K resolution, and delivers a premium visual experience when graphics performance really matters. Windows 10 OS, Linux are supported, and Advantech WISE-PaaS/SignageCMS, Web-based content management software, is also free on offer. We've designed the DS-082 in the smallest possible form factor, for optimized performance.
Warranty
Limited Warranty: 2 Year
Highlights
Power by AMD Ryzen V1000/R1000 processor
Powerful graphic engine - AMD Radeon HD graphics
19mm-thin chassis ideal for space-limited installation
3/4 HDMI display output, resolution up to 4K(3840 x 2160)
Cable-less design for easy maintenance
Supports WISE-PaaS/DeviceOn and Embedded Software APIs
Supports WebAccess/SignageCMS for intuitive signage content managing, remote monitoring and control
Specifications
General Information
Manufacturer
Advantech Co., Ltd
Manufacturer Part Number
DS-082GBF-U0A1E
Brand Name
Advantech
Product Model
DS-082
Product Name
DS-082 Ultra-slim 3/4 Display Digital Signage Player
Packaged Quantity
1
Product Type
Digital Signage Appliance
Interfaces/Ports
USB
Yes
HDMI
Yes
Serial
Yes
Number of USB 2.0 Ports
2
Number of USB 3.0 Ports
2
Memory
Standard Memory
32 GB
Memory Technology
DDR4 SDRAM
Network & Communication
Ethernet
Yes
Physical Characteristics
Mount Type
Wall Mountable, Desk Mountable
Height
0.7"
Width
7.1"
Depth
7.5"
Weight (Approximate)
1.92 lb
Power Description
Input Voltage
19 V DC
Processor & Chipset
Processor Type
Ryzen
Processor Model
V1605B
Processor Speed
2 GHz
Software
Operating System
Windows 10, Linux
Video
Scan Format
2160p
Warranty
Limited Warranty
2 Year
Miscellaneous
Package Contents
1 x DS-082 Ultra-slim 3/4 Display Digital Signage Player
1 x 19V Power adapter
1 x China RoHS
2 x Wall Mount Brackets
1 x User's Manual (En/TC/SC)
4 x Rubber foot and screws
Environmentally Friendly
Yes
Environmental Compliance
China Restriction of Hazardous Substances (China RoHS)
