SKU
LTT334
Category
Label/Receipt Printers
Overview
The LTT324 Label printer offers professional printing for any budget. It's affordable, easy-to-use making it ideal for a variety of labeling applications. The LTT324 is engineered for reliability and longevity, has a dual-wall framed construction and all-metal printhead to reduce replacement parts and decrease printer downtime.
It can print direct thermal and thermal transfer labels and includes Bartender Label Printing Software, making the LTT324 suitable for most labeling printing applications and a complete label printing solution.
Features:
• Thermal Transfer and direct thermal printing
• 5 IPS (127mm/s) high printing speed
• TSPL Emulation (EPL, ZPL, DPL)
• Support Ribbons up to 300m (984 ft)
• 8MB SDRAM, 8MB Flash
• 203 dpi resolution
• Bartender Label Printing Software
Warranty
Limited Warranty: 1 Year
Highlights
A smart choice for carrying out high volume label printing in multiple areas with reduced cost of ownership
203 maximum print resolution (dpi) for better reliance and added usability
Produce high-quality documents with this monochrome printer to increase your productivity
Enjoy the optimal performance in today's on-demand labeling applications
Optimize your workflows by sharing the resources of the printer via Ethernet connectivity
4.53" maximum label width for your convenience and feasible usability
70" maximum label length for dependable, desired results
Supports label media type for dependable, efficient results with maximum productivity
Dual Wall Frame feature for maximum efficiency and convenience
Comes with 8 MB standard memory to ensure maximum efficiency with great quality printing results
Specifications
Environmental Conditions
Operating Temperature
41°F (5°C) - 104°F (40°C)
Operating Relative Humidity
10% - 90%
Storage Temperature
-40°F (-40°C) - 140°F (60°C)
Storage Relative Humidity
10% - 90%
General Information
Manufacturer
3nStar, Inc.
Manufacturer Part Number
LTT334
Brand Name
3nStar
Product Model
LTT334
Product Name
4" Direct Thermal and Thermal Transfer Label Printer
Product Type
Direct Thermal/Thermal Transfer Printer
Interfaces/Ports
USB
Yes
USB Standard
USB 2.0
Media Types & Handling
Media Type
Label, Continuous Label, Gap, Black Mark, Fanfold, Punched Label
Media Sensor
Black Mark Sensor, Reflective Media Sensor, Cover Open Sensor, Gap Sensor, Ribbon Low/End Sensor
Media Thickness
9.84 mil
Maximum Roll Diameter
5"
Maximum Label Width
4.53"
Maximum Label Length
70"
Memory
Standard Memory
8 MB
Flash Memory
8 MB
Network & Communication
Ethernet
Yes
Ethernet Technology
Ethernet
Physical Characteristics
Product Color
Black
Height
6.7"
Width
11.1"
Depth
9.1"
Weight (Approximate)
5.64 lb
Power Description
Power Source
AC Supply, DC, Power Adapter
Software
Operating System Supported
Windows
Linux
Android
Mac OS
Technical Information
Recommended Use
Label Print
Print Color Capability
Monochrome
Maximum Mono Print Speed
5 in/s
Maximum Print Resolution (dpi)
203
Maximum Print Length
70"
Maximum Print Width
4.09"
Barcode Symbology Supported
PDF417, QR Code, Data Matrix, Code 39, Code 93, Code 128 UCC, Code 128, Codabar, Interleaved 2 of 5, EAN-8, EAN-13, EAN 128, UPC-A, UPC-E, EAN and UPC 2(5) Digits Add-On, MSI, Plessey, POSTNET, China Post, GS1 DataBar, Code 11, AZTEC, Maxi Code, 1D, 2D
Connectivity Technology
Wired
Features
Dual Wall Frame
Warranty
Limited Warranty
1 Year
Fonts & Emulation
Language Emulation
TSPL, EPL, ZPL, DPL
Miscellaneous
Package Contents
4" Direct Thermal and Thermal Transfer Label Printer
Windows Labeling software driver and user manual CD
