Genuine 3nStar through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
LTT324
Category
Label/Receipt Printers
Overview
The LTT324 Label printer offers professional printing for any budget. It's affordable, easy-to-use making it ideal for a variety of labeling applications. The LTT324 is engineered for reliability and longevity, has a dual-wall framed construction and all-metal printhead to reduce replacement parts and decrease printer downtime.
It can print direct thermal and thermal transfer labels and includes Bartender Label Printing Software, making the LTT324 suitable for most labeling printing applications and a complete label printing solution.
Features:
• Thermal Transfer and direct thermal printing
• Bartender Label Printing Software
• TSPL, EPL, ZPL, DPL Emulation
• 5 IPS high printing speed
• Support Ribbons up to 300m (984 ft)
• 8MB SDRAM, 8MB Flash
• 203 dpi resolution
• Double-walled clamshell design
• Black mark reflective sensor, Cover open sensor, Gap sensor
• Support PDF417, QR Code, Data Matrix 2D
• USB Interface and Ethernet Interface
Highlights
A smart choice for carrying out high volume label printing in multiple areas with reduced cost of ownership
203 maximum print resolution (dpi) for better reliance and added usability
Produce high-quality documents with this monochrome printer to increase your productivity
Delivers high-speed, hassle-free labeling solution for your business needs
4.53" maximum label width for dependable, desired results
Supports label media type for better reliance and maximum usability
Direct Thermal/Thermal Transfer Printer with desktop application/usage provides maximum usability with better reliance
Dual Wall Frame feature for maximum efficiency and convenience
Comes with 8 MB standard memory for timely printing with added reliability
Wired connectivity technology allows convenient and reliable connectivity for maximum efficiency
Specifications
Environmental Conditions
Operating Temperature
41°F (5°C) - 104°F (40°C)
Operating Relative Humidity
10% - 90%
Storage Temperature
-40°F (-40°C) - 140°F (60°C)
Storage Relative Humidity
10% - 90%
General Information
Manufacturer
3nStar, Inc.
Manufacturer Part Number
LTT324
Brand Name
3nStar
Product Name
4" Thermal Transfer and Direct Thermal Label Printer (LTT324)
Product Type
Direct Thermal/Thermal Transfer Printer
Interfaces/Ports
USB Host
Yes
USB
Yes
Media Types & Handling
Media Type
Label, Continuous Label, Gap, Black Mark, Fanfold
Media Sensor
Black Mark Sensor, Reflective Media Sensor, Cover Open Sensor, Gap Sensor
Media Thickness
9.84 mil
Maximum Roll Diameter
5"
Maximum Label Width
4.53"
Memory
Standard Memory
8 MB
Network & Communication
Ethernet
Yes
Ethernet Technology
Ethernet
Physical Characteristics
Product Color
Black
Height
7.6"
Width
9.1"
Depth
11.8"
Weight (Approximate)
5.45 lb
Power Description
Power Source
AC Supply
Technical Information
Recommended Use
Label Print
Print Color Capability
Monochrome
Maximum Mono Print Speed
5 in/s
Maximum Print Resolution (dpi)
203
Maximum Print Width
4.25"
Barcode Symbology Supported
PDF417, QR Code, Data Matrix, Code 39, Code 93, Code 128 UCC, Code 128, Codabar, Interleaved 2 of 5, EAN-8, EAN-13, EAN 128, UPC-A, UPC-E, EAN and UPC 2(5) Digits Add-On, MSI, Plessey, POSTNET, China Post, GS1 DataBar, Code 11, AZTEC, Maxi Code
