Vertiv Avocent Commercial MultiViewer KVM Switch | 4 port | Dual AC Power
Commercial Desktop KVM Switches | Commercial KVM Switch | Dual Head | Secure Keyboard | 4 to 8 Port | 3-Year Full Coverage Factory Warranty - Optional Extended Warranty Available
- SKU
- SVMV240DPH-400
- Category
- KVM Switchboxes
MSRP$5,730.00
$4,018.93
Save 30%In stock: 175
Genuine Vertiv through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- SVMV240DPH-400
- Category
- KVM Switchboxes
Overview
The Vertiv Avocent Commercial MultiViewer KVM continues to provide the KVM solution required in accessing both classified and non-classified data. Through the use of an all new video port, the Avocent Commercial MultiViewer KVM accepts either a standard HDMI or DP connector cable when the input/target video port has a universal connector. The Avocent Commercial Multiviewer KVM can be used in either a single or dual display projection scenario with up to 16 computers on a single screen and features such as tiling, windowing, and touch screen.
More from the Manufacturer
SMALL SPACE, BIG CAPABILITIES
The Vertiv Avocent MultiViewer KVM Switch packs powerful capabilities in a small desktop footprint, ideal for areas with limited space. By keeping multiple critical systems in the user’s field of vision, the MultiViewer enhances the user’s ability to multitask.
VIDEO QUALITY AND FLEXIBILITY
The MultiViewer KVM Switch presents users with the widest array of video connections in the industry, including Display Port and HDMI. Resolution up to 4k @ 30Hz delivers extremely high accuracy, with video playing at the highest possible definition.
FULL-SERVICE SUPPORT
Vertiv is a world leader in KVM switch technology and provides a wide range of service solutions to troubleshoot and resolve issues in the field. Vertiv stands behind every MultiViewer KVM Switch with a two-year, full-coverage factory warranty and optional extended warranty.
Security
Interact with various security classifications on a single screen, with Smart-card Common Access Card (CAC) or biometric readers for authentication across multiple secure computers.
Cursor Navigation Switching (CNS)
With CNS, the MultiViewer allows the keyboard and mouse to seamlessly transition when moving the cursor across window borders. An essential feature when controlling and viewing content from many sources in a variety of viewing modes.
Ease of Use
The MultiViewer’s flexible screen and window layout options can be navigated through its touch screen. Works with HDMI and DP, affording users flexible display options.
SVMV240DPH-400
Ports: 4
Video Type: 1x DP / HDMI universal port
Max Resolution: UHD 4K (3840x2160) @ 30Hz
Keyboard and Mouse : 1 x USB 2.0 Type B
USB Accessory: 1 x USB 3.0 Type B
Analog Audio: 3.5mm Speaker & 3.5mm Microphone
Height
: 1.7 in (43 mm)
Width
: 13.7 in (348 mm)
Depth
: 5.0 in (127 mm)
Weight :
3.35 lbs / 1.6 Kg
Mounting Option
: Desk Mount - DMK-09
SVMV280DPH-400
Ports: 8
Video Type: 1x DP / HDMI universal port
Max Resolution: UHD 4K (3840x2160) @ 30Hz
Keyboard and Mouse : 1 x USB 2.0 Type B
USB Accessory: 1 x USB 2.0 Type B
Analog Audio: 3.5mm Speaker
Height
: 2.6 in (66 mm)
Width
: 17.4 in (442 mm)
Depth
: 7.2 in (183 mm)
Weight : 8.2 lbs / 3.7 Kg
Mounting Option
: Rack Mount Included
Warranty
Limited Warranty: 2 Year
About Vertiv
Digital Continuity Solutions Vertiv brings together hardware, software, analytics, and ongoing services to ensure a customer’s digital infrastructure and vital applications run continuously, perform optimally, and scale with business needs Vertiv is a U.S. based, publicly-traded (NYSE: VRT), global manufacturer of power, thermal and IT infrastructure products and services. By bringing together hardware, software and on-going services, Vertiv offers solutions that ensure uninterrupted, reliable, safe operations of vital data applications that run continuously and perform-optimally. Vertiv possesses a rare combination of expertise and solutions that ensures connectivity and availability across any and all network facilities, anywhere in the world. Our portfolio includes the most respected brands in the industry including Avocent (networking and remote management), Geist (rack PDUs, monitors, sensors), and Liebert (UPS, power and thermal). Visit Vertiv.com for more information. Our Brands Avocent The power of being there When you need to take control of multiple IT devices across a room or across geographies, you can rely on market-leading Avocent or Cybex keyboard, video, and mouse (KVM) switches and serial consoles to provide easy, single-point access to valuable system data. Since 1981 Avocent has been developing and manufacturing industry-leading KVM switches and serial consoles to deliver easy, single-point access to valuable system data in order to control and simplify management of multiple IT devices. Vertiv’s Avocent solutions have helped over 200,000 customers worldwide by providing faster provisioning, simplified management, reduced mean time to repair, enhanced security, and lower operating costs. Geist Reliable power management Ensuring data center availability and business continuity requires that the last link in the power chain, the rack power distribution unit (rPDU), operates as intended to support dynamic operations in the areas of power, cooling, monitoring, and overall data center infrastructure management (DCIM). Geist designs and manufactures industry-leading technology and software to power, cool, monitor and manage critical data center infrastructure. On-site engineering, reliability, conformance and compliance allow us to design, manufacture, and ship PDUs so they arrive when you need them. Customers have peace of mind knowing Geist’s dedicated compliance and reliability engineering team ensure conformance to global standards for reliability, safety, and accuracy. Liebert Protecting the power and environment of your mission critical electronic systems Your data center and edge computing sites are the core of your business. Intelligent, efficient power and thermal infrastructure are critical to ensuring continuous access to vital applications and data. Liebert power and thermal management systems are designed to protect your IT environment and adapt to your changing needs. Liebert provides global power and thermal management solutions with a portfolio of most efficient and reliable power and cooling technologies in the market. Liebert offers a complete line of energy-efficient and reliable technologies including UPS, racks, rack enclosures, rack cooling, and PDUs. These award-winning technologies offer unmatched efficiency and reliability for mission-critical applications, as well as controls to optimize uptime. Architects of Continuity As Architects of Continuity, Vertiv solutions help customers build future-ready digital infrastructures that deliver continuity across large infrastructure (AC power, DC power, energy storage, industrial solutions, thermal) and IT and edge infrastructure (edge systems, IT systems, rack, rack PDU, rack thermal, rack UPS) applications. Customers can choose to work with a trusted Vertiv advisor or order products online via their preferred IT distributors, resellers and marketplaces. To learn more, visit Vertiv.com today!
Highlights
- Simultaneously view multiple computers on a single monitor.
- Ability to interact with various security classifications on a single screen.
- With CNS, keyboard and mouse transitions seamlessly when moving the cursor across window borders.
- Direct interaction with any application through touch screen capabilities.
- Smart-card (CAC) or biometric readers for authentication across multiple secure computers.
Specifications
| Package Contents |
|
|---|---|
| Product Type | KVM Switchbox |
| Manufacturer Part Number | SVMV240DPH-400 |
| Packaged Quantity | 1 |
| Limited Warranty | 2 Year |
| Weight (Approximate) | 3.50 lb |
| Form Factor | Desktop |
| Manufacturer | Vertiv |
| Product Model | SVMV240DPH-400 |
| Product Name | 4 Port MultiViewer KVM |
| Product Line | MultiView |
| Rack Height | 1U |
| Brand Name | Vertiv AVOCENT |
| Input Voltage Range | 100V AC to 240V AC |
| Country of Origin | United States |
| Height | 1.7" |
| Width | 5" |
| Depth | 13.7" |
| Environmentally Friendly | Yes |
| Maximum Video Resolution | 3840 x 2160 |
| Maximum Operating Distance | 10 ft |
| USB | Yes |
| HDMI | Yes |
| Number of HDMI Ports | 6 |
| VGA | No |
| Network (RJ-45) | No |
| Number of USB Ports | 5 |
| DisplayPort | Yes |
| PS/2 Port | No |
| Number of DVI Ports | 0 |
| Number of Computers Supported | 4 |
| Number of Local Users Supported | 1 |
| TAA Compliant | Yes |
