Overview
This 2-port multi-speed PoE+ injector serves as Power Sourcing Equipment (PSE) and enables Ethernet speeds of 10/100/1000Mbps. This mid-span inline injector can transmit network data and power up to 328ft (100m) for two Powered Devices (PD).
Versatile PoE Injector
Dual-port PoE injector supports the IEEE 802.3af and IEEE 802.3at PSE standards and delivers up to 30W output (52V/0.580A). Connect a remote PoE device to a network at a location where there is no power source, but an Ethernet cable already exists. This includes access points, IP cameras, VoIP phone systems, IPTV and access controls. The flexible design allows for either desktop or surface-mount use.
Streamlined Cable Management
All Ethernet cables can be routed from one side of the unit for efficient and organized cable management. The compact design (3.2x1x1.8in(82x25x46mm) ensures straightforward integration into existing network infrastructure, saving space and time during installation.
Warranty
Limited Warranty: 2 Year
About StarTech.com
The StarTech.com Advantage
We simplify the lives of IT Professionals by making it easy to find the connectivity accessories and information they need and getting products
to their project sites quickly.
StarTech.com products are designed by IT pros, for IT pros, to meet their rigorous technical performance requirements.
Who We Are
While we may manufacture IT connectivity accessories, StarTech.com is truly in the business of making the lives of IT professionals easy.
Founded in 1985 in London, Ontario, Canada by Paul Seed and Ken Kalopsis, StarTech.com has always been dedicated to solving technology problems faced by IT professionals. Originally known as StarTech Computer Accessories, the company had very humble beginnings as a “Visa Card” funded operation, manufacturing products like computer dust covers in the basement of a house. By focusing on the needs of our customers and continual innovation, StarTech.com has evolved into a global organization offering accessories that support over 200 different technologies, from legacy to the latest.
StarTech.com Founder and CEO, Paul Seed’s dedication to making IT solutions easy to implement has not wavered, nor has his passion for the community. From individual contributions to organization wide campaigns, StarTech.com is committed to staying connected to the community and supporting non-profit organizations across the globe.
Highlights
TWO-PORT POE+ INJECTOR: Power Sourcing Equipment provides up to 30W PoE/PoE+ and 1Gbps to two Powered devices; Level-4 ESD protection (15kV air and 8kV contact) and LAN transformer enhance device safety and maintain signal quality with reduced EMI
NETWORK COMPATIBILITY: Auto-negotiation between 10/100/1000Mbps; Deliver data and power to up to two Powered Devices (PDs) up to 328ft (100m) with Cat5/5e/6/6a cabling; Surge protection up to 2kV
HASSLE-FREE INSTALLATION: Wall-mountable w/front facing mounting ears and screw holes molded into the housing; Streamline deployment without additional software; Connect the PoE injector to the network (switch/router)/remote PD via standard cabling
APPLICATIONS: Provides more power and bandwidth over 2x RJ45 interfaces to demanding PoE devices such as IP cameras and enterprise grade Wi-Fi 6/6E or 7 access points; Compatible w/1000Base-T/100Base-TX/10Base-T Ethernet
TECH SPECS: 4x RJ45 ports (2x data input, 2x data output + power); 30W max output, 52V 0.580A output per port; Compliant with IEEE 802.3af and IEEE 802.3at; 10/100/1000Mbps & 1Gbps; 9K jumbo frames; Dimensions 3.2x1x1.8-inch(82x25x46mm)
Specifications
General Information
Manufacturer
StarTech.com
Manufacturer Part Number
AF221C-POE-INJECTOR
Brand Name
StarTech.com
Product Name
30W PoE+ Injector
Packaged Quantity
1
Product Type
PoE+ Injector
Interfaces/Ports
Input Ports
RJ-45
Output Ports
PoE+
Physical Characteristics
Color Family
Black
Product Color
Black
Form Factor
Desktop/Surface/Wall Mountable
Weight (Approximate)
2.10 oz
Power Description
Input Voltage
120 V AC, 230 V AC
Maximum Output Voltage
52 V DC
Maximum Output Current
580 mA
Maximum Output Power
30 W
Technical Information
Protection Type
Surge Protection
Warranty
Limited Warranty
2 Year
Miscellaneous
Package Contents
30W PoE+ Injector
1 x Power Adapter
1 x Quick-Start Guide
Compatibility
Compatible Products: Access Points IP Cameras VoIP Phone Systems IPTV Access Controls
