Solidigm? D7-P5520 Series (7.68TB, 2.5in PCIe 4.0 x4, 3D4, TLC) Generic Single Pack
Server Device Supported - 1 DWPD - 14336 TB TBW - 7100 MB/s Maximum Read Transfer Rate - 256-bit AES Encryption Standard - 5 Year Warranty - Bulk - 1
- SKU
- SSDPF2KX076T11Z
- Category
- Hard Drives/Solid State Drives
Request pricing
Confirmed with stock and TAA status before any payment.
Genuine SOLIDIGM through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- SSDPF2KX076T11Z
- Category
- Hard Drives/Solid State Drives
Overview
The Industry's Most Advanced PCIe 4.0 Portfolio. Performance-Tuned for the Real World.
Our broadest and highest-performing family of TLC 3D NAND SSDs, Solidigm? D7-P5520 and D7-P5620 drives (formerly Intel®), are the latest addition to the performance-optimized D7 series. These drives provide standard endurance and medium endurance, respectively, across an extended range of capacities and form factors. Building from multiple generations of PCIe 4.0 and deep industry insight, this is the industry's most advanced PCIe 4.0 portfolio with performance tuned for real-world applications. They efficiently accelerate compute and storage workloads in cloud and enterprise across a breadth of 1U and 2U server configurations. Designed and tested with zero tolerance for data errors and consistently durable performance, they can be deployed with the utmost confidence.
Product series highlights
Compared to the previous generation of PCIe 4.0 products, performance has been significantly boosted across the board, enabling workload acceleration in mixed and read-intensive applications.
More from the Manufacturer
Highlights
- Is power and energy-efficient to ensure maximum reliability
- Internal drive type for maximum efficiency and dependability
- For highly mixed and mainstream workload environments requiring low latency for improved user experience, the D7-P5520 delivers consistent, exceptional performance where it counts
- With the stunning reading speed of 7100 MB/s, get faster boot times and improved overall computing performance
- Write speed of 4200 MB/s enables you to perform write-related tasks in seconds rather than minutes
- PCI Express NVMe 4.0 x4 interface provides quick data transfer and greater throughput
- 256-bit AES encryption to protect your precious and valuable data from unauthorized access
- 2.5" form factor for added reliability and dependability
Specifications
| Product Type | Solid State Drive |
|---|---|
| Device Supported | Server |
| Storage Capacity | 7.68 TB |
| Manufacturer Part Number | SSDPF2KX076T11Z |
| Packaged Quantity | 1 |
| Limited Warranty | 5 Year |
| Weight (Approximate) | 5.82 oz |
| Drive Type | Internal |
| Form Factor | 2.5" |
| Manufacturer | SOLIDIGM |
| Product Name | D7-P5520 Solid State Drive |
| Package Type | Bulk |
| Product Series | D7-P5520 |
| Brand Name | SOLIDIGM |
| Height | 0.6" |
| Wireless LAN | No |
| Encryption Standard | 256-bit AES |
| Maximum Read Transfer Rate | 7100 MB/s |
| Maximum Write Transfer Rate | 4200 MB/s |
| Drive Interface | U.2 |
| Drive Interface Standard | PCI Express NVMe 4.0 x4 |
| Random 4KB Read | 1100000IOPS |
| Random 4KB Write | 220000IOPS |
| Endurance (DWPD) | 1 |
| Endurance (TBW) | 14336 TB |
| Mean Time Between Failures (MTBF) | 228.2 Year |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Maximum Sequential Read | 6.93 GB/s |
| Maximum Sequential Write | 4.10 GB/s |
