Floor Mountable, Ceiling Mountable
1920 x 1200 - Front, Front Ceiling, Rear Ceiling, Ceiling - 2160p - 20000 Hour Normal Mode - WUXGA - 3,000,000:1 - 20000 lm - HDMI - USB - Network (RJ-45) - Education, Museum, Rental & Staging, Presentation - 5 Year Warranty
MSRP$47,839.00
$36,323.05
Save 24%Special order — estimated OEM lead time 3–8 weeks. Order today and we expect to receive stock between Oct 19 and Nov 23, then process your delivery right after.
Genuine Sharp through authorized distribution — NDAA §889 screened before checkout.
Powerful LCD installation projector with an RB laser light source supports new, demanding projection applications.
Powerful Tools
• Multi-display support with Picture by Picture/Picture in Picture.
• TileMatrix (internal multi-screen splitter) enables 4Kx2K resolution utilizing 4 projectors without the need for external hardware.
• Built-in daisy chain capabilities support multi-display applications.
• Seamlessly blend multiple images with integrated edge blending capabilities.
Integrated
• 4K Ready - Display stunning 4K 60P content using Sharp's proprietary high performance video processing/scaling chip without the loss of critical details.
• Integrated software applications such as AMX Beacon, Crestron Roomview, Extron XTP and PJ Link allow for complete control system support.
• Learning of basic control of competitors product reduces the need for reprogramming of a control system lowering the cost of your installation by eliminating the need for costly reprogramming of a control system. (Supports competitors commands, call Sharp for complete list.)
Flexible
• Enjoy greater installation flexibility with motorized bayonet style lenses providing quick and easy exchanges. Lens throw distances range from 4.25 to 141ft.
• Roll-free installation capabilities make this projector ideal for almost any install environment, including portrait orientation.
Laser
• RB (Red and Blue) Laser system achieves 92% of the DCI color space bringing content to life.
• Images appear immediately after power on due to instantaneous start up of the laser.
• Inorganic optical components create longer lifetime and greater peace of mind.
Filter Free
• Filter free LCD laser projector that is virtually maintenance free!
• IP5X certified Sealed LCD cooling system prevents dust from reaching the optics and eliminates the need for a filter.
• External air never enters the optical path.
• Dust artifacts cannot influence picture quality or decrease image brightness.
Additional Warranty Information: Registered owners receive a five (5) years or 20,000 hours (whichever comes first) parts and labor warranty including InstaCare next business day exchange. Limited Warranty: 5 Year
| Display & Graphics | |
|---|---|
| Native Resolution | 1920 x 1200 |
| Graphic Mode | WUXGA |
| Maximum Resolution | 4096 x 2160 |
| General Information | |
| Manufacturer | Sharp |
| Manufacturer Part Number | XP-A201U-B |
| Brand Name | Sharp NEC Display |
| Product Series | A |
| Product Model | XP-A201U-B |
| Product Name | A XP-A201U-B LCD Projector |
| Product Type | LCD Projector |
| Image | |
| Standard Mode Brightness | 20000 lm |
| Contrast Ratio | 3,000,000:1 |
| Interfaces/Ports | |
| HDMI | Yes |
| SDI Standard | 3G-SDI |
| USB | Yes |
| Network (RJ-45) | Yes |
| Lamp | |
| Number of Lamps | 1 |
| Lamp Type | Laser |
| Normal Mode Lamp Life | 20000 Hour |
| Physical Characteristics | |
| Form Factor | Floor Mountable, Ceiling Mountable |
| Height | 12.2" |
| Width | 25.6" |
| Depth | 26" |
| Weight (Approximate) | 85.32 lb |
| Power Description | |
| Operating Power Consumption | 1530 W |
| Standby Power Consumption | 900 mW |
| Projection Lens | |
| Minimum Diagonal Image Size | 80" |
| Maximum Diagonal Image Size | 41.67 ft |
| Minimum Projection Distance | 42.96" |
| Maximum Projection Distance | 141 ft |
| Technical Information | |
| Projection Method | Front, Front Ceiling, Rear Ceiling, Ceiling |
| Video | |
| Video Signal Format | NTSC, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM |
| Video Signal Standard | HDTV |
| Output Scan Format | 2160p |
| Warranty | |
| Limited Warranty | 5 Year |
| Additional Warranty Information | Registered owners receive a five (5) years or 20,000 hours (whichever comes first) parts and labor warranty including InstaCare next business day exchange. |
| Miscellaneous | |
| Application/Usage | Education, Museum, Rental & Staging, Presentation |
| Package Contents |
|
