APC by Schneider Electric Smart-UPS RT 6000VA RM 200V to 200/100V
3U Rack-mountable - 3 Hour Recharge - 4 Minute Stand-by - 110 V AC, 220 V AC Input - 100 V AC, 200 V AC Output - 4 x NEMA 5-20R, 1 x NEMA L14-30R, 1 x NEMA L6-30R - Sine Wave
SKU
Category
Industrial UPS
MSRP$13,805.00
$12,286.45
Save 11%
Back-ordered
Special order — estimated OEM lead time 3–8 weeks. Order today and we expect to receive stock between Oct 9 and Nov 13, then process your delivery right after.
Genuine Schneider Electric through authorized distribution — NDAA §889 screened before checkout. TAA verified on request.
SKU
Category
Industrial UPS
Overview
A versatile UPS developed for the harshest power conditions in the world.
Smart-UPS On-Line provides high density, true double-conversion on-line power protection for servers, voice / data networks, medical labs, and light industrial applications. Capable of supporting loads from 1 to 20kVA in a rack/tower convertible form, the Smart-UPS On-Line is available from 2U to 12U. Recent family extensions at 15 and 20kVA enable support of power hungry blade servers or heavily loaded equipment racks. When business-critical systems require runtime in hours, not minutes, Smart-UPS On-Line can be configured with matching battery packs to comply with aggressive runtime demands. The included PowerChute management software provides unattended graceful shutdown of network operating systems. All models 5kVA and above include an integrated Network Management Card for remote management (optional on models below 5 kVA). The entire Smart-UPS On-Line family provides value to customers with demanding power environments, including very wide input voltage window, extremely tight output voltage regulation, frequency regulation, internal bypass, and input power factor correction.
Warranty
Limited Warranty: 2 Year
Highlights
Multiple output voltages - 48Vdc, 24Vdc, and 120Vac are available to power all of the equipment in the cabinet.
Specifications
Battery Information
Battery Characteristics
Maintenance-free
Battery Chemistry
Lead Acid
Backup/Run Time (Full Load)
4 Minute
Backup/Run Time (Half Load)
14 Minute
Typical Battery Recharge Time
3 Hour
General Information
Manufacturer
Schneider Electric SA
Manufacturer Part Number
SURTD6000RMXLJP3U
Brand Name
APC by Schneider Electric
Product Line
Smart-UPS
Product Name
Smart-UPS RT 6000VA RM 200V to 200/100V
Product Type
Double Conversion Online UPS
Interfaces/Ports
Network (RJ-45)
Yes
Physical Characteristics
Product Color
Black
Form Factor
Rack-mountable
Rack Height
3U
Weight (Approximate)
128.26 lb
Power Description
Load Capacity (VA)
6000 VA
Input Voltage
110 V AC, 220 V AC
Output Voltage
100 V AC, 200 V AC
Input Frequency
60 Hz
Output Frequency
60 Hz
Waveform Type
Sine Wave
Technical Information
Plug/Connector Type
NEMA L14-30P
Receptacle Type
NEMA 5-20R, NEMA L14-30R, NEMA L6-30R
Receptacle Detail
4 x NEMA 5-20R, 1 x NEMA L14-30R, 1 x NEMA L6-30R
Number of Battery & Surge Outlets
6
Overload Protection
Yes
Warranty
Limited Warranty
2 Year
Miscellaneous
Package Contents
Smart-UPS RT 6000VA RM 200V to 200/100V
CD with software
Rack mounting support rails
Smart UPS signalling RS-232 cable
User manual
Environmentally Friendly
Yes
Environmental Compliance
Registration, Evaluation, Authorization and Restriction of Chemicals (REACH), Restriction of Hazardous Substances (RoHS)
