APC Smart-UPS Modular Ultra, On-Line, 15kW scalable to 20kW N+1, Lithium-ion, Rackmount 9U, 208/240V, Network Management, Extended runtime, W/rail kit
APC Smart-UPS Modular Ultra On-Line 15kW 9U Rackmount, Scalable to 20kW N+1 Redundant 208/240V, Touchscreen, Network Management Card
- SKU
- SRYL15K20RMXLT
- Category
- Industrial UPS
MSRP$56,840.00
$36,413.59
Save 36%Back ordered — ships when restocked.
Genuine Schneider Electric through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- SRYL15K20RMXLT
- Category
- Industrial UPS
Overview
Smart-UPS? Modular Ultra provides up to 2.5x more power density in half the size and weight of comparable UPSs. Its modular design allows you to scale power or runtime as your business needs change*. The 125A supports up to 20kW of power protection. The most sustainable modular UPS of its kind, featuring best-in-class embodied carbon reduction, allows you to save money on Total Cost of Ownership compared to VRLA UPSs. *Additional 5kW power (SRYL5KPMT) and battery (SRYLBM) modules sold separately. Compatible with Genuine APC battery modules only.
More from the Manufacturer
APC Smart-UPS Modular Ultra (SRYL15K20RMXLT)
The APC Smart-UPS Modular Ultra 15kW configurable to 20kW N+1 with 120/208/240V split phase output. Its next generation semiconductor technology delivers up to 20kW in half the size of comparable UPSs. In addition to long lasting Lithium-ion batteries the weight is reduced by 60% in comparison to Lead Acid VRLA UPS. With the Embedded Network port you can monitor and manage your UPS anytime, anywhere.
Modular, scalable, redundant
With 15kW of scalable single phase power protection in 9U, Smart-UPS Modular Ultra gives you more room and 2.5x more power for IT equipment than comparable Modular UPS.
3x the life with Lithium-ion batteries
Lithium-ion lasts 3x longer than VRLA batteries and, under normal operating conditions, will not need replacement for the life of the UPS. Meaning you can save battery replacement AND labor costs up to 3x!
Visibility anytime, anywhere
Secure cloud monitoring with the EcoStruxure Ready Smart-UPS. PowerChute software for convenient monitoring and control.
Certainty in a connected world
Trusted for over 40 years Schneider Electric’s APC Brand has 120 million single-phase UPS installed worldwide. APC products are available in over 160 countries with 250 Service locations.
Hot Spots
FAQ
About APC
APC, a flagship brand of Schneider Electric, provides clean battery backup power, surge protection, and IT physical infrastructure, ensuring data is available — whenever and wherever you need it.
Comparison Table
Warranty
Limited Warranty: 5 Year
Highlights
- 9U Rackmount UPS Chassis, 3U XBP Frame, scalable to 20kW N+1 with 4 (5kW) Power and 4 Battery Module
- 125A chassis allows you to scale power protection up to 20kW N+1
- At 50% smaller & 60% lighter, fewer people are required to install
- The most sustainable modular UPS of its kind, featuring best-in-class embodied carbon reduction
- 1-Year Secure Network Management Card subscription included
Specifications
| Product Type | Double Conversion Online UPS |
|---|---|
| Display | LCD |
| Input Voltage | 208 V AC, 120 V AC, 240 V AC |
| Manufacturer Part Number | SRYL15K20RMXLT |
| Sound Emission | 65 dB |
| Packaged Quantity | 1 Pack |
| Limited Warranty | 5 Year |
| Output Voltage | 120 V AC, 208 V AC, 240 V AC |
| Form Factor | Rack-mountable |
| Manufacturer | Schneider Electric SA |
| Product Name | Smart-UPS Modular Ultra 15kW Scalable to 20kW N+1 Rackmount 208/240V |
| Network Management | Network Card |
| Brand Name | APC |
| Plug/Connector Type | Hard Wire 4-wire (2PH+N+G) |
| Country of Origin | Philippines |
| Input Frequency | 70 Hz |
| Phase | Single Phase |
| Environmentally Friendly | Yes |
| Battery Energy | 7192.8 kJ |
| Maximum Operating Temperature | 104°F (40°C) |
| Number of Batteries | 3 |
| Backup/Run Time (Half Load) | 12.40 Minute |
| Backup/Run Time (Full Load) | 5.77 Minute |
| Load Capacity (Watt) | 15 kW |
| Energy Star | Yes |
| EPO Port | Yes |
| USB (HID Compliant) Port | Yes |
| Maximum Operating Elevation | 9842.52 ft |
| Maximum Storage Elevation | 49212.60 ft |
| Storage Relative Humidity | 0% - 95% |
| Storage Temperature | 5°F (-15°C) - 113°F (45°C) |
| Input Power Factor | 0.5 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Single-use Plastic (SUP) Free Shipping Packaging | No |
