Genuine Schneider Electric through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
AR124SM
Category
Rack Equipment
Overview
The NetShelter UPS Depth Wall-Mount Enclosure offers reliability, durability, and ease-of-deployment for single-phase equipment mounted on the wall. Available in 12U, 18U, and 24U sizes, NetShelter UPS Depth Wall-Mount Enclosure is designed with an 800mm depth to accommodate a wide range of single-phase applications. Bracket-style mounting ensures quick and easy deployment. Low-profile side-mount configuration ensures the enclosure extends less than 25 inches from the wall, a perfect solution for locations with limited space. Compatible with APC's NetBotz security solutions for remote access, video surveillance, and environmental monitoring (sold separately). Maximum load capacity of 350lb ensures durability for heavy-duty equipment. Both top and bottom feature cable access openings to route, secure, and organize cables Accessory channels included to provide toolless mounting capabilities for rack PDU's and cable management accessories. Ideal for diverse segments such as retail, healthcare, distribution centers, and education, providing an efficient solution for deploying IT equipment for edge computing applications. 19" rack width, ships fully-assembled, ventilated, backed by 5-year APC warranty.
Warranty
Limited Warranty: 5 Year
Highlights
Efficient and secure edge computing solution when floor space is limited
Wallmount Rack Enclosure
24U, 800mm deep, max. load 350lb
Low-profile side-mount
Locking swing-handle
Bracket-style mounting
Cable access openings top/bottom
Ventilated
Ships pre-assembled
Includes hardware
Specifications
Application/Usage
UPS, IT Equipment
Package Contents
NetShelter 24U Wallmount Rack Enclosure Cabinet Side Mount UPS Depth
Hardware
Product Type
Rack Cabinet
Manufacturer Part Number
AR124SM
Packaged Quantity
1
Limited Warranty
5 Year
Ventilation
Yes
Weight (Approximate)
176.40 lb
Features
Cable Management
Form Factor
Wall Mountable
Manufacturer
Schneider Electric SA
Product Name
NetShelter 24U Wallmount Rack Enclosure Cabinet Side Mount UPS Depth
Product Line
NetShelter
Rack Width
19"
Rack Height
24U
Brand Name
APC
Country of Origin
Thailand
Assembly Required
No
Height
45.5"
Width
23.6"
Depth
40.8"
Maximum Weight Capacity
350 lb
Rack Depth
32.87"
Rack Type
Enclosed Cabinet
Product Material
Steel
Environmental Compliance
China Restriction of Hazardous Substances (China RoHS), Restriction of Hazardous Substances (RoHS), Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
