Height Adjustable - 46" to 65" Screen Support - 100.31 lb Load Capacity - 975 x 400 - VESA Mount Compatible - 1
MSRP$249.00
$135.41
Save 46%Special order — expected back in stock the week of Sep 7–13.
Genuine Peerless Industries through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
Peerless-AV's quick service restaurant (QSR) Menu Board Mount is designed to create a seamless mounting surface. Continuous and fixed tilt options allow all displays to be tilted at the same angle with ease, creating a flawless alignment. The QSR Menu Board Mount allows for tool-less height adjustment and four-corner depth adjustment to alleviate issues with wall imperfections and fine-tuning. The kickstand feature holds the bottom of the display away from the wall during cable connection, reducing installation time and cost. Available in landscape and portrait design options, Peerless-AV® offers a one-to-one ordering process, making the QSR Menu Board Mount the perfect mounting solution. More from the Manufacturer
SmartMount
Digital Menu Board Mount with Height and Depth Adjustment- Landscape for 46" to 65" Displays
Peerless-AV’s quick service restaurant (QSR) Menu Board Mount is designed to create a seamless mounting surface through connecting wall plates. Continuous and fixed tilt options allow all displays to be tilted at the same angle with ease, creating a flawless alignment. The QSR Menu Board Mount allows for tool-less height adjustment and four-corner depth adjustment to alleviate issues with wall imperfections and fine-tuning. The kickstand feature holds the bottom of the display away from the wall during cable connection, reducing installation time and cost. Available in Landscape and Portrait design options, Peerless-AV offers a one-to-one ordering process, making the QSR Menu Board Mount the perfect mounting solution.
Features
Tool-less vertical adjustment on each universal display adapter bracket for post install leveling and height adjustment fine tuning
Tool-less four corner depth adjustment aligns the displays on the same plane and helps alleviate issues with wall imperfections.
Included security hardware deters tampering and theft |DS-MBZ647L - landscape configuration for 46"-65" displays with mounting hole patterns 975 x 400mm (38.40"W x 15.75"H)
Easy hang wall plate allows for a single person install
The quick connect latch automatically engages the wall plate for a speedy setup
Simple one-to-one ordering process
Open wall plate reduces wall interference
Limited Warranty: 5 Year
| General Information | |
|---|---|
| Manufacturer | Peerless Industries, Inc |
| Manufacturer Part Number | DS-MBZ647L |
| Brand Name | SmartMount® |
| Product Series | DS-MBZ647L |
| Product Model | DS-MBZ647L |
| Product Name | Digital Menu Board Mount with Height & Depth Adjustment For 46" To 65" Displays |
| Packaged Quantity | 1 Unit |
| Product Type | Wall Mount |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| VESA Mount Compatible | Yes |
| Mounting Pattern | 975 x 400 |
| Form Factor | Wall Mountable |
| Height | 19.48" |
| Width | 39.98" |
| Depth | 3.09" |
| Weight (Approximate) | 10.50 lb |
| Product Information | |
| Device Supported | Menu Board, Display |
| Number of Displays Supported | 3 |
| Maximum Load Capacity | 100 lb |
| Minimum Screen Size Supported | 46" |
| Maximum Screen Size Supported | 65" |
| Height Adjustable | Yes |
| Features | Sturdy, Increlock, Adjustable Depth, Tool-less Adjustment, Kickstand, Flat, Quick Connect, Vertical Adjustment, 3-axis |
| Orientation | Landscape |
| Minimum Tilt Angle | 0° |
| Maximum Tilt Angle | 15° |
| Mount Function | Tilt, Cable Management |
| Mount Surface | Wall |
| Durability | Tamper Resistant, Theft Resistant |
| Warranty | |
| Limited Warranty | 5 Year |
| Miscellaneous | |
| Package Contents | Digital Menu Board Mount for 46"-65" Displays - Landscape Wall Plate Adapter Rails Mounting Hardware |
| Application/Usage | Wall |
| Indoor/Outdoor | Indoor |
| Assembly Required | Yes |
| Manufacturer Product Class | Menu Board Wall |
| TAA Compliant | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
