Genuine MSI through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
CUBI512M016B
Category
Barebone Systems
Overview
Small But Powerful
Bring it home when you need without any inconvenience that it can be your mini PC and your portable storage device.
PEACE of MIND
• Easy to use and make life simple
Support Up To 8K Resolution
Cubi 5 allows you to enjoy the best experience of watching movie with your family or attending online conference call while working from home or learning professional tasks at home.
Bolt To The Next Power
Thunderbolt? 4* brings Thunderbolt to USB-C at speeds up to 40 Gbps, creating one compact port that does it all - delivering the fastest, most versatile connection to any dock, display, or data device & NAS.
Embracing a wide array of interface compatibilities so that you can edit, collaborate and share seamlessly
See More, Do More
With HDMI, DP, and Thunderbolt 4, Cubi 5 allows you to extend to three monitors to preview your E-commerce content & data at home or in the office, enhancing your efficiency.
MSI Cloud Center Fast, Secure & Wireless Backup
Fast, secure, and wireless backup & download between your PC and mobile devices. Transfer files, photos, videos, and more between your PC, Android, and iOS device faster and easier than a cabled connection. You can make these files accessible to your family or team members, or you can also make files as private as you want. The decision is in your hands.
MSI Center
The MSI Center takes optimization to the next level with easily adjustable system modes; it helps to prioritize & allocate the resource on your hand to accelerate the performance of those software which you work with everyday.
STABLE & POWERFUL
Equips up to 12th Gen Intel ® Core ? i7 processor with 10 cores and 12 threads, delivering computing capability and keeping you in the flow, wherever you go. Also, enjoy more detailed, immersive viewing experience with Intel ® Iris ® Xe Graphics.
Highlights
Windows 11 Home - MSI recommends Windows 11 Pro for business
Up to 12th Gen Intel® Core? i7 Processors
Support up to 8K UHD Display
Support three displays that allow you to see more and do more
Thunderbolt 4 delivers the fastest, most versatile connection to any dock, display, or data device & NAS
Dual LAN: the best way to back up your file / secure data and prevent the hacker (with MSI exclusive BIOS)
Get all the performance benefits from USB 3.2 Gen 2 and enjoy the best data transmission experience
Experience 75% lower latency with WiFi 6E technology(optional)
FW TPM design secures your confidential data with encryption keys
Supports standard VESA-mount
Specifications
Additional Warranty Information
3 Yr Advanced Replacement
Package Contents
Cubi 5 12M-016BUS Barebone System
AC Adapter
Product Type
Barebone System
Manufacturer Part Number
CUBI512M016B
Maximum Memory Supported
64 GB
Limited Warranty
3 Year
Weight (Approximate)
8.80 oz
Form Factor
Mini PC
Manufacturer
MSI
Product Model
Cubi 5 12M-016BUS
Product Name
Cubi 5 12M-016BUS Barebone System
Processor Type
Core i5
Product Line
Cubi 5 12M
Brand Name
MSI
Operating System Supported
Windows 10 Home, Windows 10 Pro
Memory Technology
DDR4 SDRAM
Processor Model
i7-1255U
Country of Origin
China
Memory Standard
DDR4-2666/PC4-21333
Height
2.1"
Width
4.9"
Depth
4.9"
Environmentally Friendly
Yes
64-bit Processing
Yes
Chipset Manufacturer
Intel
Bluetooth
Yes
Wireless LAN
Yes
Graphics Memory Technology
DDR4 SDRAM
Graphics Memory Accessibility
Shared
Ethernet Technology
Gigabit Ethernet
Number of Total Expansion Bays
1
Maximum Power Supply Wattage
65 W
Total Number of USB Ports
6
Number of Onboard USB 2.0 Ports
2
Processor Generation
10th Gen
USB Type-C Detail
1 x USB 3.2 Gen 1 Type C
HDMI (Rear)
Yes
USB Type-C (Front)
Yes
Product Color
Black
Number of USB 3.2 Gen 1 Ports
3
Color Family
Black
Total Number of Memory Slots
2
Energy Efficiency Compliance
Energy-related Products Directive (ErP)
Environmental Compliance
Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE)
