Special order — estimated OEM lead time 3–8 weeks. Order today and we expect to receive stock between Oct 6 and Nov 10, then process your delivery right after.
Genuine Leviton Mfg through authorized distribution — NDAA §889 screened before checkout. TAA verified on request.
SKU
Category
Connectors
Country of origin
United States
Country of origin is manufacturer-reported and can vary by production lot. Where TAA applies to your purchase, we verify the shipping unit's origin on request.
Overview
The Atlas-X1 Category 5e Component-Rated UTP QuickPort Jack is part of a complete Atlas-X1 Cat 5e UTP system, ideal for the most demanding network applications. The jack supports emerging technologies and will easily adapt to network trends.
Highlights
Independently tested and guaranteed to exceed all component, permanent link, and channel margins
Patented Retention Force Technology (RFT) protects against tine damage and increases system longevity
For Power over Ethernet, RFT maintains contact force between plug and connector, preventing arcing from intermittent disconnects
Unique design supports tool-free termination/re-termination and requires no specialized termination tool
Short connector design supports a wider range of applications (e.g. shallow boxes, enclosures, bend radius)
Terminates from 26 to 22 AWG solid or stranded conductors for use on various cable types
Robust IDCs can withstand 20 re-termination cycles and connector contacts are tested for 750 plug-mating cycles to ensure system longevity
Available in 13 ANSI/TIA-606-C compatible colors
Select jacks supplied with interchangeable icons (voice, data, A/V, and blank, color coded to match the connector face) for easy identification and tracking of data, voice, or other functions
Jacks with internal shutter protects against dust and debris
Specifications
General Information
Manufacturer
Leviton Mfg. Company, Inc
Manufacturer Part Number
5EUJK-RW5
Brand Name
Leviton
Product Line
Atlas-X1
Product Name
Atlas-X1 Cat 5e UTP QuickPort Jack, White
Product Type
Network Connector
Physical Characteristics
Product Color
White
Product Material
Metal, Die-cast Zinc
Contact Material
Copper Alloy
Technical Information
Connector Type
RJ-45 Network - Female
Connector Details
1 x RJ-45 Network - Female
Contact Plating
Gold
Shielding
No
Compatible Wire Gauge
22-26 AWG
Mount Type
Surface Mount
Features
Retention Force Technology (RFT), Stranded, Dust Protection, Debris Resistant, PoE
