Lenovo P5620 3.20 TB Solid State Drive - 2.5" Internal - U.2 (PCI Express NVMe 4.0 x4) - Mixed Use
Server Device Supported - 3 DWPD - 17920 TB TBW - 6700 MB/s Maximum Read Transfer Rate - Hot Swappable - 1 Year Warranty - 1
- SKU
- 4XB7A76782
- Category
- Hard Drives/Solid State Drives
$1,724.58
Back ordered — ships when restocked.
Genuine Lenovo through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- 4XB7A76782
- Category
- Hard Drives/Solid State Drives
Overview
The P5620 SSDs are part of the growing family of PCIe 4.0 SSDs that match the performance of the ThinkSystem V2 family of servers. By having a Gen 4 host interface, sequential performance is doubled compared to Gen 3 SSDs. The NVMe host interface also maximizes flash storage performance and minimizes latency. The P5620 SSDs drives offer 40% and 60% improvements in latency over SAS and SATA SSDs respectively.
Lenovo Mixed Used SSDs like the P5620 SSDs are suitable for mixed read-write and general-purpose data center workloads, however their NVMe PCIe interface means the drives also offer high performance. Overall, these SSDs provide outstanding IOPS/watt and cost/IOPS for enterprise solutions.
Highlights
- Store unlimited documents, pictures, and videos with the impressive 3.20 TB capacity
- Power and energy-efficient design ensures maximum reliability for your SSD
- The write speed of 3600 MB/s enables rapid data transfer, allowing write-related tasks to be completed in seconds and significantly enhancing productivity
- PCI Express NVMe 4.0 x4 interfaceguarantees quick and reliable data transfer
- With the remarkable reading speed of 6700 MB/s enjoy faster boot times and significantly improved overall computing performance
- 2.5" form factorenables hassle-free and easy usage, enhancing overall efficiency
- Ensures fast and dependableaccess to data with non-volatile memory, maintaining consistent performance and reliability
Specifications
| Additional Warranty Information | The SSDs carry a 1-year, customer-replaceable unit (CRU) limited warranty. |
|---|---|
| Package Contents |
|
| Product Type | Solid State Drive |
| Compatibility | ThinkSystem Servers: SD650 V2 (7D1M) SD650-N V2 (7D1N) |
| Device Supported | Server |
| Storage Capacity | 3.20 TB |
| Hot Swappable | Yes |
| Manufacturer Part Number | 4XB7A76782 |
| Packaged Quantity | 1 |
| Limited Warranty | 1 Year |
| Weight (Approximate) | 5.15 oz |
| Drive Type | Internal |
| Form Factor | 2.5" |
| Manufacturer | Lenovo Group Limited |
| Product Name | ThinkSystem 2.5" 15mm U.2 P5620 3.2TB Mixed Use NVMe PCIe 4.0 x4 Trayless SSD |
| Product Series | P5620 |
| Brand Name | Lenovo |
| Height | 0.6" |
| Width | 2.8" |
| Depth | 3.9" |
| Environmentally Friendly | Yes |
| Wireless LAN | No |
| Maximum Read Transfer Rate | 6700 MB/s |
| Maximum Write Transfer Rate | 3600 MB/s |
| Drive Interface | U.2 |
| Drive Interface Standard | PCI Express NVMe 4.0 x4 |
| Random 4KB Read | 1000000IOPS |
| Random 4KB Write | 341000IOPS |
| Endurance (DWPD) | 3 |
| Endurance (TBW) | 17920 TB |
| Endurance Type | Mixed Use |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE) |
