Lenovo 3.20 TB Solid State Drive - 2.5" Internal - U.2 (SFF-8639) NVMe (PCI Express 3.0 x4) - 3.5" Carrier - Mixed Use
Server Device Supported - 3 DWPD - 17520 TB TBW - 3200 MB/s Maximum Read Transfer Rate - Hot Swappable - 1 Year Warranty - 1
- SKU
- 4XB7A08534
- Category
- Hard Drives/Solid State Drives
MSRP$6,999.00
$4,799.31
Save 31%Back ordered — ships when restocked.
Genuine Lenovo through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- 4XB7A08534
- Category
- Hard Drives/Solid State Drives
Overview
The ThinkSystem KCM51V Mainstream NVMe solid-state drives (SSDs) in capacities from 800 GB to 6.4 TB are advanced data center SSDs optimized for mixed read-write performance, endurance, and strong data protection for Lenovo servers. They are engineered for greater performance and endurance in a cost-effective design, and to support a broader set of workloads.
Suggested uses: Data warehousing, Web servers, Media streaming, and Video on Demand (VOD).
Highlights
- 2.5-inch drive (U.2) or 3.5-inch drive bay form factor
- Based on the Toshiba CM5 drives
- Third Generation BiCS 3D NAND 64 layer TLC
- 3 drive-write-per-day (DWPD) SSD for mixed read-write workloads
- Direct PCIe 3.0 x4 connection for each NVMe drive, resulting in up to 4 GBps overall throughput.
- Full Power-Loss-Protection and End-to-End Data Protection
- Low power consumption (maximum 18 W)
Specifications
| Package Contents |
|
|---|---|
| Product Type | Solid State Drive |
| Compatibility | Lenovo ThinkSystem Servers: SR630 (7X01/7X02) SR650 (7X05/7X06) |
| Device Supported | Server |
| Storage Capacity | 3.20 TB |
| Hot Swappable | Yes |
| Manufacturer Part Number | 4XB7A08534 |
| Packaged Quantity | 1 |
| Limited Warranty | 1 Year |
| Weight (Approximate) | 4.59 oz |
| Drive Type | Internal |
| Form Factor | 2.5" |
| Manufacturer | Lenovo Group Limited |
| Product Name | ThinkSystem 3.5" KCM51V 3.2TB Mainstream NVMe PCIe 3.0 x4 Hot Swap SSD |
| Brand Name | Lenovo |
| Height | 0.6" |
| Width | 2.8" |
| Depth | 3.9" |
| Environmentally Friendly | Yes |
| Wireless LAN | No |
| Maximum Read Transfer Rate | 3200 MB/s |
| Maximum Write Transfer Rate | 2900 MB/s |
| Drive Interface | U.2 (SFF-8639) NVMe |
| Drive Interface Standard | PCI Express 3.0 x4 |
| Drive Carrier | Yes |
| Drive Carrier Width | 3.5" |
| Endurance (DWPD) | 3 |
| Endurance (TBW) | 17520 TB |
| Endurance Type | Mixed Use |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
