1 Display(s) Supported - 42? to 86? Screen Support - 200 lb Load Capacity
MSRP$575.00
$501.37
Save 13%Special order — estimated available by September 10, 2026.
Genuine Legrand through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
The Chief Fusion micro-adjustable tilt display wall mount solves top flat panel installation problems, offering flexible adjustments for large displays with a low-profile display mounting solution and includes new benefits of added stability, faster install, improved lateral shift, easier cable management and enhanced security. The integrated teardrop design speeds up wall plate installation by allowing pre-installation of the bolts to the wall and Control Zone Leveling for post-installation fine tuning of height and leveling. Feel confident in your installation with Chief's ClickConnect technology that offers an audible click when the screen safely engages with the mount and set screws to keep the mount rigid, stable and secure throughout the life of installation. Built in cable stand provides easy access under the screen.
More from the Manufacturer
Chief Fusion Wall Mount Displays
Chief's Fusion® tilt wall mounts were developed based on installer feedback and direct observations of installers in the field. Favorite Fusion® features include Centerless shift, Centris tilt, ControlZone leveling adjustment and ClickConnect Latching.
Benefits included increased stability, fast installation, easy cable management and security.
The installer-inspired Fusion tilt mount solves top flat panel installation problems, offering flexible adjustments for large displays with a low-profile display mounting solution.
Features
ControlZone™ Height & Roll Adjustment is an industry-first feature for post-installation fine-tuning of height and leveling of the entire configuration, not just the display.
Centerless™ Lateral Shift allows for up to 16” (406 mm of post-installation lateral shift - 8” (203 mm) left/right of uprights. Enhancements include up to 3” (76 mm) of lateral shift in the wall plates. Dual-stud versions only.
Centris® Low-Profile Tilt provides effortless, tool-free tilting by using the center of gravity to balance the screen.
ClickConnect® Tool-Free Latching creates an audible click when the screen safely engages with the mount. A built-in cable stand allows easy access under the screen. Tuck Quick Store cords out of sight with the magnetized end.
Fusion Wall Mount Diagram
Micro-Adjustable Fixed and Tilt Mounts
Limited Warranty: 10 Year
Chief, a brand of Legrand | AV, has delivered proven product and service excellence since 1978. Their installer-inspired design is a philosophy that guides their engineers and designers to create AV solutions that solve installation problems, propelling AV projects towards completion. With numerous product awards and patented designs, Chief is recognized for creating high-quality products that are easy to install and maintain.
| General Information | |
|---|---|
| Manufacturer | Legrand Group |
| Manufacturer Part Number | LTM1U-G |
| Brand Name | Chief |
| Product Line | Fusion Wall Tilt |
| Product Series | LTM |
| Product Model | LTM1U-G |
| Product Name | Fusion Large Adjustable TV Wall Mount - For 42-86 Inch TVs - Tilt TV Mount |
| Product Type | Wall Mount |
| Physical Characteristics | |
| Color Family | Black |
| Product Color | Black |
| Mounting Pattern | 100 x 100, 878 x 500 |
| Height | 17" |
| Width | 34.75" |
| Depth | 2" |
| Product Information | |
| Device Supported | TV |
| Number of Displays Supported | 1 |
| Maximum Load Capacity | 200 lb |
| Minimum Screen Size Supported | 42" |
| Maximum Screen Size Supported | 86" |
| Features | Adjustable, Leveling System, Cable Management, Lateral Adjustment, ClickConnect Latching, Tilt |
| Warranty | |
| Limited Warranty | 10 Year |
| Miscellaneous | |
| Package Contents |
|
| Compatibility | TV |
| Country of Origin | United States |
| TAA Compliant | Yes |
