AMX DXLite 4K60 Transmitter

AMX DXLite transmitters and receivers leverage HDBaseT technology to distribute audio, video, and USB 2.0 over a single category cable. AMX DXLite supports 4K60 4:4:4, HDCP 2.2, and HDR video, providing compatibility with the latest source devices and displays. DXLite can be used point-to-point (with a transmitter connected directly to a receiver over a single cable) or be used for distant transport in conjunction with an AMX Incite All-in-One Presentation Switcher.

The onboard USB 2.0 available on the DXLite allows for easy distribution of USB signals between the transmitter and receiver. A USB device, such as an AMX Acendo Vibe conferencing soundbar, can be mounted at the display and connected to a DXLite receiver. A laptop can then connect to the transmitter at the table, with USB and video distributed over category cable.

Common Applications

Ideal for supporting cost-effective conferencing in BYOD meeting environments.

Features

• 4K60 4:4:4 and HDCP 2.2 Support over HDBaseT with Display Stream Compression (DSC) - Visually lossless compression and future-proof support

• Power over HDBaseT - Can be powered from HDBaseT inputs which means there is no need for an additional power source at the table

• USB 2.0 Transmission - Connect devices such as cameras, keyboard, mouse and other USB devices

• Compatible - With the AMX Incite presentation switcher and DXLite RX
