Amprobe ACDC-3400 IND AC/DC CAT IV TRMS Clamp Meter
1 kA AC - 1 kA DC - Auto Power Off, Data Hold, Backlight
- SKU
- ACDC-3400 IND
- Category
- Multimeters
MSRP$785.99
$641.76
Save 18%Back ordered
Back ordered — ships when restocked.
Genuine Fluke through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- ACDC-3400 IND
- Category
- Multimeters
Overview
The Amprobe ACDC-3400 clamp multimeter is CAT IV rated to add an extra level of safety for high voltage, industrial or utility testing applications. It is an AC/DC current clamp meter and a voltage meter all in one.
This clamp-on electrical multimeter includes True RMS sensing for accuracy and dependability and extra large jaws to clamp around conductors up to 2" (51 mm) in diameter.
Highlights
- True-rms sensing increases measurement accuracy in noisy environments
- Measures AC/DC current up to 1000 A, AC voltage to 1000 V and DC voltage to 750 V, frequency, resistance, and capacitance and duty cycle
- Peak hold checks transients and motor start currents for spikes
- Relative zero displays the difference between the actual reading and a stored reference value and may be used with any function or range
- Audible continuity helps quickly identify opens and shorts
- Auto and manual ranging for measurement speed and flexibility
- Data hold holds the reading on the display for further analysis
- Diode test quickly finds voltage drops
- Accommodates conductors up to 2" (51 mm) in diameter
- Safety rated to CAT IV 600 V and CAT III 1000 V
- Auto power off conserves battery life
- Backlight makes it easy to read even in dark conditions
Specifications
| Package Contents |
|
|---|---|
| Product Type | Clamp Meter |
| Manufacturer Part Number | ACDC-3400 IND |
| Features | Auto Power Off, Data Hold, Backlight |
| Manufacturer | Fluke Corporation |
| Product Model | ACDC-3400 IND |
| Product Name | ACDC-3400 IND AC/DC CAT IV TRMS Clamp Meter |
| Brand Name | Amprobe |
| Measurement Type | AC Voltage, DC Voltage, AC Current, DC Current, Resistance, Capacitance, Frequency, Continuity, Temperature, Duty Cycle |
| True RMS | Yes |
| Ranging Type | Auto/Manual |
| Maximum AC Current Measurement | 1 kA |
| Maximum DC Current Measurement | 1 kA |
| Maximum Resistance Measurement | 66 Mega Ohm |
| Maximum Capacitance Measurement | 0.0066F |
| Maximum Temperature Measurement | 1832°F (1000°C) |
| Maximum Frequency Measurement | 1 MHz |
| Jaw Size | 2.01" |
| Display Counts | 6600 |
