Genuine Elo Touch Solutions through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
E898054
Category
Handheld Terminals
Overview
Designed to support your everyday business, the Elo Pay M60 delivers an enterprise grade, Android mobile POS computer ready to help you assist customers. This all-in-one device offers built-in capabilities to accept payments, conduct business, and track sales all from the palm of your hand. Complete with a 6-inch HD touch display, integrated payment, flexible Android 10 OS and Qualcomm 660 octa-core processor, the Elo Pay M60 handheld computer provides seamless integration, effortless provisioning and simplified device management via EloView® or your preferred 3rd-party MDM.
With rugged Corning Gorilla Glass technology to provide protection against unintentional spills, the Elo Pay M60 is purpose-built to endure commercial use. From table service and line busting to curbside pickup and accepting payment almost anywhere, the Elo Pay M60 allows your employees to be ready on the go.
Fully integrated payment via NFC, EMV and MSR (BCR on select models)
Secure - PCI-PTS 6.x Certified
Optional accessories including docking station, multi-unit device charger, handstrap and more
Seamless Provisioning with EloView, Google Zero Touch or GMS
Highlights
Touch panel gives your workforce ease, along with familiar and flexible operation, thus improving overall efficiency on a daily basis
The secure wireless connectivity allows your employees to stay productive while away from their desks
6" LCD screen is ideal for scan intensive applications
Streamline your business processes with an imager that point-shoots with high-performance scanning
Android 10 OS makes you more productive and creative
3 GB RAM / 32 GB flash memory helps run applications rapidly and stores the mightiest databases
Store your additional data in the supported microSD memory card
Wired/Wireless connectivity technology delivers exceptional performance to offer maximum usability
Experience the versatility of Bluetooth connectivity with your Elo Handheld Terminal
Phone-size form factor is comfortable to utilize in intensive or non-intensive scan environments
Specifications
Application/Usage
Field Sales/Service
Battery Chemistry
Lithium Polymer (Li-Polymer)
Package Contents
Pay M60SC Handheld Terminal
USB Type-C Charger
Quick Install Guide
Battery
Product Type
Handheld Terminal
Flash Memory
32 GB
Manufacturer Part Number
E898054
Screen Resolution
1440 x 720
Limited Warranty
1 Year
Standard Memory
3 GB
Weight (Approximate)
14.22 oz
Brightness
430 Nit
Operating System
Android 10
Connectivity Technology
Wired/Wireless
Features
Corning Gorilla Glass, Water Resistant, Fast Charging, Drop Resistant, Multi-color LED Notification
Form Factor
Phone-size
Manufacturer
Elo Touch Solutions, Inc
Product Model
M60SC
Product Name
Pay M60SC Handheld Terminal
Processor Speed
2.20 GHz
Processor Type
Snapdragon
Product Line
Pay
Screen Size
6"
Sensor Type
Light Sensor, Proximity, Accelerometer
Brand Name
Elo
Screen Mode
HD
Memory Card Supported
microSD, SDHC, SDXC
Processor Model
660
Processor Core
Octa-core (8 Core)
Battery Capacity
4000 mAh
Touchscreen
Yes
Battery Included
Yes
Processor Manufacturer
Qualcomm
Bluetooth
Yes
Wireless LAN
Yes
Display Screen Type
LCD
Wireless LAN Standard
IEEE 802.11 a/b/g/n/ac
Bluetooth Standard
Bluetooth 5.0
Image Sensor Type
Imager
GPS
Yes
Battery Voltage
3.80 V
USB
Yes
Cellular Data Connectivity Technology
LTE
Cellular Network Supported
WCDMA
Rear Camera
Yes
Rear Camera Resolution
8 Megapixel
Number of SIM Card Supported
1
SIM Size Supported
Nano
Illumination Type
LED
USB Type-C
Yes
Scan Mode
Trigger
Storage Temperature
-22°F (-30°C) to 140°F (60°C)
Near Field Communication (NFC)
Yes
Illumination Color
Green
Ingress Protection (IP) Rating
IP54
Rugged
Yes
Upgradable Operating System
Android 12
Google Mobile Services (GMS)
Yes
Scan Engine Model
SE4720
Scanning Capability
2D, 1D
Operating Temperature
32°F (0°C) to 122°F (50°C)
Humidity (Non-condensing)
5% to 95%
Global Navigation Satellite System (GNSS) Supported
BeiDou/Galileo/GLONASS
Environmental Compliance
China Restriction of Hazardous Substances (China RoHS)
