SKU
N785-CH75W-AC
Category
Power Supplies
Overview
Powers Your Tripp Lite N785-CH12 12-Port Media Converter Chassis
This 75-watt AC power supply works with the Tripp Lite N785-CH12 media converter chassis to provide redundant power that helps prevent unwanted and expensive downtime. One N785-CH75W-AC comes pre-installed with the N785-CH12 to provide primary power. An additional power supply is also recommended as a replacement part.
Warranty
Limited Warranty: 3 Year
About Eaton
Eaton is an intelligent power management company dedicated to improving the quality of life and protecting the environment for people everywhere. We are guided by our commitment to do business right, to operate sustainably and to help our customers manage power ─ today and well into the future. By capitalizing on the global growth trends of electrification and digitalization, we're accelerating the planet's transition to renewable energy and helping to solve the world's most urgent power management challenges.
Highlights
Limits current to the safety level and manages electrical faults
Delivers 12 V to ensure that your device is always ready to use
The maximum output power of 75 W boosts up the performance
Specifications
General Information
Manufacturer
Eaton Corporation
Manufacturer Part Number
N785-CH75W-AC
Brand Name
Tripp Lite series
Product Name
75W Power Supply
Packaged Quantity
1
Product Type
Power Supply
Physical Characteristics
Form Factor
Box
Height
3.4"
Width
9.3"
Depth
10.4"
Weight (Approximate)
3.75 lb
Power Description
Input Voltage
120 V AC, 230 V AC
Output Voltage
12 V
Output Voltage Detail
12 V @ 6.5 A
Output Current
6.50 A
Output Power
75 W
Warranty
Limited Warranty
3 Year
Miscellaneous
Compatibility
Tripp Lite N785-CH12 Media Converter Chassis
Country of Origin
Taiwan
Environmentally Friendly
Yes
Environmental Compliance
Restriction of Hazardous Substances (RoHS), Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
