Eaton Tripp Lite Series 750VA 450W 120V Line-Interactive Cloud-Connected UPS with Remote Monitoring, 12 NEMA 5-15R Outlets (6 Surge + 6 Surge and Battery Backup), 5-15P Plug, Desktop
Surface/Desktop/Tower/Wall Mountable - AVR - 8 Hour Recharge - 3 Minute Stand-by - 120 V AC Input - 120 V AC Output - Single Phase - Pulse-width Modulated Sine Wave - USB - LED Display - 12 x NEMA 5-15R - 6 x Battery/Surge Outlet - Network Card
- SKU
- AVR750UNC
- Category
- General Purpose UPS
MSRP$330.69
$191.87
Save 42%Back ordered — ships when restocked.
Genuine Eaton through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- AVR750UNC
- Category
- General Purpose UPS
Overview
750VA/450W/120V Battery Backup for Digital Signage and Home/Office Networks
The AVR750UNC line-interactive cloud-connected UPS system with AVR protection provides reliable battery backup and AC power protection against blackouts, brownouts, overvoltages, surges and line noise for computers, routers, gaming systems, ATMs, security systems, digital signage and other home/office networking equipment.
Easy-to-Use Cloud-Enabled Remote Monitoring Powered by Brightlayer
Eaton's cloud-based remote monitoring app offers convenient setup, control and management of a single UPS or a larger deployment. Scan the QR code on the UPS to download the app to your mobile device. Receive alerts, push configurations, silence alarms or control outlet banks using a mobile app or web browser. Being able to monitor and access an army of UPS systems from a remote location helps reduce the number of site visits, saving you time and money. The unit's NFC (Near-Field Communication) area lets you configure network settings instantly from your mobile device.
Allows Time to Back Up Critical Files During a Blackout
The AVR750UNC restarts automatically once power is restored, regardless of battery charge level, saving you a costly site visit. During short blackouts and brownouts, the AVR750UNC switches to battery power to keep connected equipment running. This allows you enough time to save data and complete a safe shutdown in case of a longer outage.
Premium Protection from Surges and Line Noise Helps Your Equipment Perform Better
Rated for 316 joules of surge suppression, the AVR750UNC and all 12 NEMA 5-15R outlets protect connected devices from the harmful effects of power surges. The AVR750UNC also filters out disruptive electromagnetic interference (EMI) and radio frequency interference (RFI) that can destroy data and contribute to lengthy downtime. Four outlets are set apart from the others to allow connection of bulky transformers.
Automatic Voltage Regulation (AVR) Corrects Low- and High-Voltage Conditions
AVR protects your equipment from incremental hardware damage, data loss and performance problems caused by brownouts and overvoltages. The AVR750UNC can correct brownouts as low as 89V and overvoltages as high as 145V back to nominal 120V power continuously, all while keeping the battery fully charged and ready to take over in case of power failure.
Easy Preventative Maintenance and Initial Troubleshooting
The AVR750UNC's self-test capability and user-replaceable internal battery can extend the life of the UPS and minimize disruption to operations. A resettable circuit breaker helps prevent dangerous system overloads.
Home-Friendly Alarm and Diagnostic LEDs Keep You Informed 24/7
An audible alarm and a red LED indicate a low battery or fault condition. A green LED indicates power and line/battery mode status. The audible alarm can be disabled via the remote monitoring app, which will still respond to silenced alarms.
Hardened Housing Compatible with Versatile Deployment Options
The flatpack housing allows use in locations with higher ambient temperatures (operating temperature range: 32° to 104°F / 0° to 40°C). The AVR750UNC's small size is suitable for desktop or floor placement. Keyhole slots on the bottom allow wall mounting. The five-foot power cord with NEMA 5-15P plug connects to any compatible AC outlet.
Warranty
Limited Warranty: 3 Year
About Eaton
Eaton is an intelligent power management company dedicated to improving the quality of life and protecting the environment for people everywhere. We are guided by our commitment to do business right, to operate sustainably and to help our customers manage power ─ today and well into the future. By capitalizing on the global growth trends of electrification and digitalization, we're accelerating the planet's transition to renewable energy and helping to solve the world's most urgent power management challenges.
Highlights
- Cloud-based dashboard allows 24/7 remote monitoring via browser or mobile app
- Cloud-connected UPS sets up in minutes to start protecting your devices
- Create account with two-factor authentication for an additional layer of security
- NFC technology allows easy configuration of network settings from your mobile device
- Lets you control outlets or shut down devices using your PC, tablet or smartphone
- Sends you fast alert notifications and responses through email or SMS
- 3-year limited warranty
Specifications
| Application/Usage | Equipment, Digital Signage, Home/Office, Network, Computer, Router, ATM, Security System, Desktop Computer, Computer Peripheral, Audio/Video Equipment, Tablet, Smartphone |
|---|---|
| Battery Chemistry | Lead Acid |
| Package Contents |
|
| Product Type | Line-interactive UPS |
| Circuit Breaker | Yes |
| Display | LED |
| Input Voltage | 120 V AC |
| Manufacturer Part Number | AVR750UNC |
| Limited Warranty | 3 Year |
| Output Voltage | 120 V AC |
| Weight (Approximate) | 15.84 lb |
| Features | Audible Alarm, Cold Start Function |
| Form Factor | Surface/Desktop/Tower/Wall Mountable |
| Status Indicators | LED Indicators: Low Battery Fault Condition Line/battery Mode Status |
| Input Current | 20 A |
| Manufacturer | Eaton Corporation |
| Product Model | AVR750UNC |
| Product Name | AVR750UNC 750VA Surface/Desktop/Tower/Wall Mountable UPS |
| Network Management | Network Card |
| Overload Protection | Yes |
| Surge Energy Rating | 316 J |
| Surge Suppression | Yes |
| Thermal Dissipation | 12.02 W |
| Waveform Type | Pulse-width Modulated Sine Wave |
| Brand Name | Tripp Lite series |
| Plug/Connector Type | NEMA 5-15P |
| Input Voltage Range | 89 V AC - 145 V AC |
| Output Frequency | 50 Hz, 60 Hz |
| Alarm | Low Battery, Overload, Battery Mode, Replace Battery, Fault |
| Country of Origin | Vietnam |
| Cord Length | 5 ft |
| Height | 4.13" |
| Width | 7.48" |
| Depth | 12.01" |
| Input Frequency | 50 Hz, 60 Hz |
| Phase | Single Phase |
| Receptacle Type | NEMA 5-15R |
| USB | Yes |
| Minimum Operating Temperature | 32°F (0°C) |
| Maximum Operating Temperature | 104°F (40°C) |
| Network (RJ-45) | Yes |
| Backup/Run Time (Half Load) | 11 Minute |
| Backup/Run Time (Full Load) | 3 Minute |
| Battery Characteristics | Valve-regulated |
| Load Capacity (VA) | 750 VA |
| Load Capacity (Watt) | 450 W |
| EMI/RFI Noise Filter | Yes |
| Replaceable Battery | Yes |
| Energy Star | Yes |
| AVR | Yes |
| DC System Voltage | 12 V DC |
| Energy Saving | Green Energy-Saving |
| Maximum Operating Elevation | 10000 ft |
| Number of Battery & Surge Outlets | 6 |
| Storage Temperature | 5°F (-15°C) - 113°F (45°C) |
| Number of Surge-only Outlets | 6 |
| Transfer Time | 6 ms |
| Typical Battery Recharge Time | 8 Hour |
| Output Power Factor | 0.63 |
| Receptacle Detail | 12 x NEMA 5-15R |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE) |
