4U Rack/Tower - 3 Hour Recharge - 10.90 Minute Stand-by - 230 V AC Input - 200 V AC, 208 V AC, 220 V AC, 230 V AC, 240 V AC Output - Single Phase - Pure Sine Wave - Serial Port - USB - LCD Display - 4 x NEMA L6-30R Receptacle(s) - INDGW-M2 Card, Relay-MS Card, Network-M3 Card, RS-232
MSRP$17,912.00
$14,053.75
Save 22%Special order — estimated available by September 10, 2026.
Genuine Eaton through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
Features | 8kVA/8kW/208V Battery Backup for Distributed IT and Edge Networks
This 9PX G2 rack-mount online double-conversion lithium-ion UPS system provides reliable, low-maintenance battery backup and AC power protection against blackouts, brownouts, surges and line noise that can damage critical IT equipment or destroy data. The 9PX8KG2-L is ideal power management for IT managers, data center managers, electrical contractors, integrators, specifying engineers and other end users in business, edge computing, education, government, healthcare, retail and other networking applications.
Delivers Maximum Power Reliability with Best-in-Class Efficiency
With unity power factor (8000VA/8000W output), the 9PX8KG2-L maximizes power reliability and allows you to support servers, PoE (Power over Ethernet) switches and other networking equipment. The most efficient UPS system in its class, it complies with the latest ENERGY STAR standards to reduce greenhouse gas emissions and to save you money on energy and cooling costs. Load segments with energy metering help you optimize energy use.
Lithium-Ion Batteries Designed for Long Life
Advanced lithium-ion battery technology offers a service life of eight to 10 years, which is at least three times longer than traditional lead-acid batteries while weighing 40 percent less. Not only does this reduce maintenance and replacement costs, but it also makes the UPS lighter, more efficient and ideal for deployments where reliability and longevity matter. These lithium iron phosphate (LiFePO4) batteries allow you to work through most power failures and give you enough time to safely save files and shut down your system in case of a prolonged blackout.
Reliable, Expandable Battery Backup with Enhanced Management
Eaton's exclusive battery management system (BMS) monitors battery performance, charge cycles and active temperature to provide advance notice when batteries need replacement. You can also connect up to 10 extended battery modules (9PXEBM192RTG2-L, sold separately), which are smaller and lighter than VRLA modules, to add necessary runtime during prolonged power outages.
Included Gigabit Network Interface Offers 24/7 Remote Access and Cybersecurity
The NETWORK-M3 cybersecure network management card enables full remote configuration and management, including load shedding, reboots of connected equipment and safe shutdowns. UPS firmware can also be flashed remotely through the NETWORK-M3 without dropping the load, so you don't have to plan for downtime. The card meets both UL 2900-1 and IEC 62443-4-2 standards for cybersecurity, which were developed to address the vulnerability of connected devices to known malware/exploits and to protect businesses from these risks.
High-Visibility LCD Interface Keeps You Informed at a Glance
The high-contrast color LCD provides control settings and critical information to help diagnose any issues. A large color LED bar makes it easy to diagnose UPS status from a distance and quickly locate units that require attention. The interface rotates to accommodate both rack-mount and tower configurations, and it tilts up to 45 degrees for more comfortable viewing.
Limited Warranty: 5 Year
We're dedicated to improving people's lives and the environment with power management technologies that are more reliable, efficient, safe and sustainable. Every day, all around the world, people depend on technology, transportation, energy and infrastructure to live and work. With rapid growth in electrification, an energy transition driven by climate change and explosive growth in connectivity, we’re well positioned to solve the world’s toughest electrical and mechanical power management challenges. Because that’s what really matters. And we’re here to make sure it works.
| Battery Information | |
|---|---|
| DC System Voltage | 192 V DC |
| Battery Chemistry | Lithium Iron Phosphate (LiFePO4) |
| Battery Capacity | 12000 mAh |
| Backup/Run Time (Full Load) | 10.90 Minute |
| Backup/Run Time (Half Load) | 22 Minute |
| Battery Life | 10 Year |
| Hot Swappable | Yes |
| Typical Battery Recharge Time | 3 Hour |
| Replaceable Battery | Yes |
| Controls/Indicators | |
| Status Indicators | LED status bar |
| Display & Graphics | |
| Display | LCD |
| Environmental Conditions | |
| Minimum Operating Temperature | 32°F (0°C) |
| Maximum Operating Temperature | 104°F (40°C) |
| Thermal Dissipation | 333.22 W |
| General Information | |
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | 9PX8KG2-L |
| Brand Name | Eaton |
| Product Series | 9PX G2 |
| Product Model | 9PX8KG2-L |
| Product Name | 9PX8KG2-L 8000VA Rack/Tower UPS |
| Product Type | Double Conversion Online UPS |
| Interfaces/Ports | |
| Serial Port | Yes |
| USB | Yes |
| EPO Port | Yes |
| Management | |
| Network Management | INDGW-M2 Card, Relay-MS Card, Network-M3 Card, RS-232 |
| Alarm | UPS Failure, Low Battery, Overload, UPS Fault, Battery Fault, Remote Shutdown |
| Physical Characteristics | |
| Height | 6.80" |
| Width | 17.30" |
| Depth | 28.60" |
| Rack Height | 4U |
| Form Factor | Rack/Tower |
| Weight (Approximate) | 132.28 lb |
| Power Description | |
| Load Capacity (VA) | 8000 VA |
| Load Capacity (Watt) | 8000 W |
| Input Voltage | 230 V AC |
| Input Current | 38.40 A |
| Output Voltage | 200 V AC, 208 V AC, 220 V AC, 230 V AC, 240 V AC |
| Output Frequency | 50 Hz, 60 Hz |
| Waveform Type | Pure Sine Wave |
| Output Power Factor | 1 |
| Technical Information | |
| Plug/Connector Type | Hardwired |
| Receptacle Type | Hardwired, NEMA L6-30R |
| Receptacle Detail | 4 x NEMA L6-30R |
| EMI/RFI Noise Filter | Yes |
| Phase | Single Phase |
| Efficiency Detail | 97% (AC Mode), 99.4% (Eco Mode) |
| Application/Usage | Mission Critical Equipment, IT, Network, IT Equipment, Data Center, Business, Edge Computing, Education, Government, Healthcare, Retail, Server, Switch |
| Surge Suppression | Yes |
| Features | Audible Alarm |
| Warranty | |
| Limited Warranty | 5 Year |
| Miscellaneous | |
| Package Contents |
|
| Energy Star | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
