SKU
ICU504A
Category
Cable Extenders
Overview
Industry-first USB 3, 2 and 1 extender
Extend all your USB devices. This USB Extender provides the ability to connect all USB 3.1 Gen 1 (5 Gbps) device types and is backward compatible with USB 2.0 and 1.1. This unique solution is the only USB extender capable of CAT X 3.0 extension.
Great extension length
Get your USB connections where they need to go. This USB 3.1 Extender extends up to 100 meters over CAT6A/7 cable.
Faster than any other USB extender
Never worry about slow USB transfer speeds again. This USB 3.1 Extender provides USB speeds 10x faster than any other USB 2 extender on the market. This makes large file and multiple file transfers significantly faster, saving you valuable time.
Additionally, these hyper-fast USB transfer speeds mean superior support for USB 3 cameras.
Leverage your existing network infrastructureThe USB Extender features an Ethernet side channel that lets you use your existing network infrastructure without having to run additional dedicated cable. Also, it allows users to connect Ethernet capabilities of devices through the extender without running a separate cable, making it perfect for PTZ applications.
Highlights
USB Speeds 10x faster than any other USB 2 extender on the market
Extends up to 100m over CAT6A and CAT7
Four auto-negotiating USB 3, 2 & 1 ports at remote extender
True plug-and-play; no software drivers required
100/1000-Mbps Ethernet side channel; LAN pass-through
Works with all major operating systems: Windows®, macOS?, Linux® and Chrome OS?
Two-year warranty
Specifications
Package Contents
1 x Local Extender
1 x Remote Extender
1 x USB 3.1 Cable
2 x International Locking AC Adapter
2 x Country-Specific Power Cord
1 x Quick Start Guide
Product Type
USB Extender
Input Voltage
240 V AC
Manufacturer Part Number
ICU504A
Limited Warranty
2 Year
Manufacturer
Black Box Corporation
Product Name
USB 3.1 Extender over CATx - 4-Port
Brand Name
Black Box
Country of Origin
China
Height
1.3"
Width
9.1"
Depth
5.4"
Environmentally Friendly
Yes
Maximum Data Transfer Rate
640 MB/s
USB
Yes
Network (RJ-45)
Yes
Number of USB Ports
4
Maximum Extended Range
328.08 ft
Environmental Compliance
Waste Electrical and Electronic Equipment Directive (WEEE), Restriction of Hazardous Substances (RoHS), Restriction of Hazardous Substances (RoHS) 2
