Genuine Black Box through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
IC408A-R2
Category
Cable Extenders
Overview
Extend a USB 2.0 connection beyond the 16 ft (5 m) limitation over a CATx link 328 ft (100 m) or over an Ethernet LAN to four peripherals. Extend a USB connection beyond the desktop to peripherals for applications such as indistrial control, KVM extension, Digital Sinage, Remote Desktop USB connections, Security web cameras and access control, Medical device connectivity, USB Web device sharing: printing scanning , storage. The extender can be used in industrial control, factory floor, classroom, or meeting room applications The extender supplies up to 600 mA to the downstream USB device and offers reliable operation with USB 1.1 and USB 2.0 devices.
Highlights
Transmits up to 328 feet (100 m) over CATx or over a LAN.
Includes a local unit and remote unit with four USB 2.0 ports.
Supplies 1A max power to the USB devices.
Extends USB signals at speeds up to 480 Mbps.
Plug and play. No drivers to install on your computer.
Works with Windows®, Mac® OS X®, and Linux® systems.
Specifications
Additional Information
Distance Between local and remote units in a direct CATx application and between network switches: 328 ft. (100 m)* maximum
Network Operation When used to extend over an Ethernet IP network: Data traffic: Layer 2; Management traffic: Layer 3 (dynamic or static IP assignments)
Operating Humidity 20 to 80%, noncondensing
Operating Temperature 32 to 122° F (0 to 50°C)
Power Input From 100-240 VAC, 50-60 Hz adapter (included)
Power Output 24 VDC
RoHS Yes
Speeds Up to 480 Mbps*
Standards FCC (Class B), IC (Class B), CE (Class B); ESD Rating: EMC EN-61000-4-2:2001 8kV Contact, 16kV Air
Storage Humidity 10 to 90%, noncondensing
Connectors Local unit: USB: (1) USB Type B F; Interconnect: (1) RJ-45; Remote unit: USB: (4) USB Type A F; Interconnect: (1) RJ-45
Dimensions 1"H x 3.9"W x 3"D (2.6 x 10 x 7.6 cm)
Indicators On each unit: (4) LEDs (Power, Link, Host, Activity)
Weight 3.1 lb (1.4 kg)
Package Contents
Local Extender Unit
Remote Extender Unit
USB Cable
Power Adapter
US Power Cord
Quick Start Guide
Product Type
USB Extender
Input Voltage
240 V AC
Manufacturer Part Number
IC408A-R2
Limited Warranty
2 Year
Certifications & Standards
CE
Manufacturer
Black Box Corporation
Product Name
USB 2.0 Extender - CATx/LAN, 4-Port
Brand Name
Black Box
Country of Origin
China
Height
1"
Width
3.9"
Depth
3"
Environmentally Friendly
Yes
Maximum Data Transfer Rate
60 MB/s
USB
Yes
Number of Network (RJ-45) Ports
2
Network (RJ-45)
Yes
Number of USB Ports
5
Maximum Extended Range
328.08 ft
Environmental Compliance
Waste Electrical and Electronic Equipment Directive (WEEE), Restriction of Hazardous Substances (RoHS), Restriction of Hazardous Substances (RoHS) 2
