Genuine ATEN Technology through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
CS1188DP4C
Category
KVM Switchboxes
Overview
ATEN PSD PP v4.0 Secure KVM Switch CS1188DP4C is specifically designed to meet the stringent security requirement of secure defense and intelligence installations. ATEN PSD PP v4.0 Secure KVM Switch CS1188DP4C is compliant with PSD PP v4.0 (Protection Profile for Peripheral Sharing Device, Version 4.0) standard certified by the National Information Assurance Partnership (NIAP).
ATEN PSD PP v4.0 Secure KVM Switch CS1188DP4C provides isolation between computer sources and peripherals while sharing a single keyboard, mouse, monitor, speaker set, and Common Access Card (CAC) reader between connected computers of various security classifications. Compliance with PSD PP v4.0 ensures peripheral sharing capabilities provide maximum user data security when switching port focus, preventing unauthorized data flows or leakage between connected sources. Key protections include isolation and unidirectional data flow, restricted peripheral connectivity and filtering, user data protection, configurable device filtration and management, strict audio filtration, and always-on tamper-proof design, keeping sensitive assets isolated and providing advanced security and a user friendly design for instantly secure deployment.
To enhance security, ATEN PSD PP v4.0 Secure KVM Switch CS1188DP4C only offers manual switching methods including front panel pushbuttons and Remote Port Selector (RPS). With multi-layered security, ATEN PSD PP v4.0 Secure KVM Switch CS1188DP4C ensures high-level desktop security and data safekeeping for applications such as government and military agencies, healthcare providers, banking and finance institutions, and other organizations that often handle sensitive or confidential data on separate networks.
Highlights
With this KVM Switchbox, avoid the constant switching of cables between sources
Connect up to 8 computers to 1 local users
Enjoy watching any class of content on 3840 x 2160 resolution
Establishes a rapid connection with USB devices
Desktop - Can be placed on a desktop surface as a standalone installation
Specifications
General Information
Manufacturer
ATEN Technology, Inc
Manufacturer Part Number
CS1188DP4C
Brand Name
ATEN
Product Line
Secure
Product Model
CS1188DP4C
Product Name
8-Port USB DisplayPort Secure KVM Switch with CAC (PSD PP v4.0 Compliant)
Packaged Quantity
1
Product Type
KVM Switchbox
Interfaces/Ports
USB
Yes
DisplayPort
Yes
Number of USB Ports
19
Number of DisplayPorts
9
Physical Characteristics
Form Factor
Desktop
Height
2.6"
Width
8.1"
Depth
17"
Weight (Approximate)
6.61 lb
Power Description
Input Voltage Range
100-240V
Frequency
50 Hz, 60 Hz
Technical Information
Number of Computers Supported
8
Number of Local Users Supported
1
Video
Maximum Video Resolution
3840 x 2160
Miscellaneous
Package Contents
8-Port USB DisplayPort Secure KVM Switch with CAC (PSD PP v4.0 Compliant)
