Advantech Silver Line IDP-31150 15" Class Open-frame LCD Touchscreen Monitor - 16 ms
15" Viewable - Projected Capacitive - 10 Point(s) Multi-touch Screen - 1024 x 768 - XGA - 16.2 Million Colors - 400 Nit - LED Backlight - DVI - VGA - Black - 2 Year
- SKU
- IDP-31150-P40DVB1G
- Category
- Touchscreen Monitors
$463.44
Back ordered — ships when restocked.
Genuine Advantech through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- IDP-31150-P40DVB1G
- Category
- Touchscreen Monitors
Overview
IDP-31150
15" industrial ProFlat touch monitor. 100% flat projected capacitive touch with ultra-thin profile, smooth rounded corners and rugged glass fronted for a totally contemporary outlook.
• 15" wide LCD panel with LED backlight for long service life
• Operating temperature 0 to +40° C; Storage temperature -20 to +60° C
• Regular brightness 400 CD/m2
• Resolution 1024 x 768
• Contrast ratio 800 : 1
• 80°/80°/80°/80° wide view-angle for portrait and landscape mode
• 10 points projected capacitive touch overlay
• VGA & DVI I/O interface
• IP51 rating from the front and side
The IDP-31150 is a 15" industrial grade ProFlat touch monitor with stylish silver line bezel, that responds to requirements of being durable, robust and reliable.
This range of displays marks a significant departure from the traditional industrial unit. With the most obvious change being its contemporary look and feel, the unit also features intuitive 10 point multi-touch P-CAP technology and a fully flat surface that can be easily cleaned with a wet cloth or any suitable cleaning agent.
Designed to tackle a wide range of applications, this industrial grade display uses long life durable parts that make it robust enough for the more demanding requirements.
Highlights
- The open-frame lcd touchscreen monitor is ideal for clubhouse gaming, entertainment, and self-service kiosks with reliable touchscreen performance
- XGA touchscreen supports XGA resolution up to 1024 x 768 pixels for dependable image quality in standard applications
- Projective Capacitive technology allows touch with bare fingers or thin gloves for flexibility in medical and industrial use
- LED backlight enhances color range and contrast for lifelike visuals and smooth touch navigation
- Captivating visuals with about 400 Nit brightness levels for clear and vivid touchscreen performance
- VESA mount compatibility allows flexible installation on walls or stands to suit your workspace needs
Specifications
| Package Contents |
|
|---|---|
| Product Type | Open-frame LCD Touchscreen Monitor |
| Manufacturer Part Number | IDP-31150-P40DVB1G |
| Response Time | 16 ms |
| Limited Warranty | 2 Year |
| Touchscreen Type | Projected Capacitive |
| Weight (Approximate) | 7.69 lb |
| Brightness | 400 Nit |
| Color Supported | 16.2 Million Colors |
| Features | 6H Surface Hardness, Anti-glare, On-screen Display (OSD), OnScreen Control |
| Manufacturer | Advantech Co., Ltd |
| Product Model | IDP-31150 |
| Product Name | Silver Line IDP-31150 Open-frame Touchscreen LCD Monitor |
| Product Line | Silver Line |
| Product Series | IDP-31 |
| Viewable Screen Size | 15" |
| Maximum Resolution | 1024 x 768 |
| Brand Name | Advantech |
| Screen Mode | XGA |
| Height | 11" |
| Width | 14" |
| Depth | 1.8" |
| Horizontal Viewing Angle | 160° |
| Vertical Viewing Angle | 160° |
| Environmentally Friendly | Yes |
| Backlight Technology | LED |
| VESA Mount Compatible | Yes |
| VESA Mount Standard | 100 x 100 |
| Operating Power Consumption | 18 W |
| Native Contrast Ratio | 800:1 |
| DVI | Yes |
| VGA | Yes |
| Multi-touch Screen | Yes |
| Screen Size Class | 15" |
| Product Color | Black |
| Number of Simultaneous Touchpoints | 10 |
| Color Family | Black |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
