1 10/100/1000Base-T RJ-45 port or 2-Wire Terminal Block combo port + 1 10/100/1000Base-T IEEE 802.3af/at or 1 100/1000Base-X SFP combo port
Transition Networks

1 10/100/1000Base-T RJ-45 port or 2-Wire Terminal Block combo port + 1 10/100/1000Base-T IEEE 802.3af/at or 1 100/1000Base-X SFP combo port

MEDIA CONVERTER, IP GB PoE+ over 2-wire, REMOTE UNIT

SKU
EO2PD4052-111
Category
Cable Extenders

MSRP$509.00

$369.80

Save 27%
Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Transition Networks through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
EO2PD4052-111
Category
Cable Extenders

Overview

Lantronix Ethernet Over 2-Wire Extender With PoE+ provides the ability to quickly and easily upgrade Ethernet networks with modern PoE powered IP devices without the need to replace the existing copper wire infrastructure. The extenders leverage existing 18-24 AWG unshielded twisted pair CAT 5, CAT 3 and other twisted 2-wire phone wire cabling infrastructure to extend the Ethernet network at half Gigabit speeds and provide data and power to IP devices in remote locations, saving time and money over installing new cable. NDAA Compliant, TAA Compliant

Highlights

  • Copper or fiber combo Ethernet port
  • IEEE 802.3af/at compliant Remote PoE+ port for powering cameras or other remote devices
  • Full PoE+ at 335-1,500 ft. over a single pair or 1,500-6,800 ft. over multiple pairs* dependent on cable type
  • Half-Gigabit Ethernet speeds over UTP cable at distances of 330 feet 100m or Fast Ethernet speeds at approximately 1800 feet 550m dependent on wire gauge*
  • Proprietary SELV classification prevents unintended power delivery to non-Transition Networks devices
  • Power monitoring
  • Auto Power Reset APR and power-saving mode
  • Web browser configurable
  • Plug-and-Play installation
  • Field upgradeable firmware
  • Can be managed through a single IP address
  • Auto-MDI/MDIX
  • 128 Bit AES encryption over 2-wire
  • IPv4 and IPv6 supported
  • Client for DHCP, DNS, NTP
  • Connection for optional power on Remote device
  • Preserves investment in existing UTP or twisted 2-wire infrastructure

Specifications

Package Contents
  • Ethernet Over 2-Wire Extender With PoE+
  • Power Adapter
Product TypeNetwork Extender
Input Voltage48 V DC
Manufacturer Part NumberEO2PD4052-111
Limited Warranty5 Year
ManufacturerLantronix, Inc
Product NameEthernet Over 2-Wire Extender With PoE+
Brand NameTransition Networks
Country of OriginTaiwan
Height1.3"
Width3.3"
Depth5.4"
Maximum Data Transfer Rate128 MB/s
Number of Network (RJ-45) Ports2
Network (RJ-45)Yes
Receiver Weight (Approximate)1.05 lb
Maximum Extended Range6800 ft
