StarTech Dual Port PCI Express Gigabit Ethernet PCIe Network Card Adapter, PoE/PSE, TAA
Add two Power-over-Ethernet Gigabit Ports to a PCI Express-enabled Computer - dual port pcie nic - dual port gigabit server adapter - pci express gigabit network card - pcie poe - poe nic
- SKU
- ST2000PEXPSE
- Category
- Network Interface Cards
MSRP$175.26
$165.29
Save 6%In stock: 169
Genuine StarTech.com through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- ST2000PEXPSE
- Category
- Network Interface Cards
Overview
The ST2000PEXPSE Dual Port PoE NIC provides two 10/100/1000 Mbps PoE RJ45 ports that can provide up to 25.5W of power each, combining a network data connection and power on a single cable, for less clutter and convenient installations in remote locations. This full/low profile Gigabit server adapter supports the IEEE 802.3at (Type 1 and 2) standard for a Power Sourcing Equipment (PSE) device, and can deliver 48V DC power to compliant Powered Devices (PD). This eliminates the need for a separate power source and cable for remote networked devices such as IP cameras, IP phones and wireless access points. Suitable for any PCI Express-enabled client, server or workstation, this versatile PoE network adapter supports features such as Jumbo Frames, VLAN tagging and Wake on LAN (WOL). The ST2000PEXPSE PoE NIC is backed by a StarTech.com 2-year warranty and free lifetime technical support. More from the Manufacturer More from the Manufacturer
Highlights
- Dual 10/100/1000 Mbps PoE RJ45 ports
- Supports IEEE 802.3at (Type 1, 2) Power over Ethernet standard
- Power Sourcing Equipment (PSE) design, provides data and up to 25.5W of power on each port
- Built-in SATA and LP4 Molex power connector
- Unique surge protection design helps prevent system damage in the event of lightning strikes
- Jumbo Frame support
- On-chip 48 KB Big Transmit/Receive Buffer Support
- Fully Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, and supports IEEE 802.1Q VLAN tagging, IEEE 802.1P Layer 2 Priority Encoding and IEEE 802.3x Full Duplex Flow Control
- Crossover Detection & Auto-Correction (Auto MDIX)
- Includes full and low profile/half-height installation brackets
Specifications
| Package Contents |
|
|---|---|
| Host Interface | PCI Express |
| Product Type | Gigabit Ethernet Card |
| Device Supported | PC |
| Manufacturer Part Number | ST2000PEXPSE |
| Packaged Quantity | 1 Each |
| Thickness | 700 mil |
| Weight (Approximate) | 3.70 oz |
| Form Factor | Plug-in Card |
| Manufacturer | StarTech.com |
| Product Name | Dual Port PCI Express Gigabit Ethernet PCIe Network Card Adapter - PoE/PSE |
| Network Technology | 10/100/1000Base-T |
| Brand Name | StarTech.com |
| Country of Origin | Taiwan |
| Height | 2.7" |
| Width | 0.7" |
| Environmentally Friendly | Yes |
| Chipset Manufacturer | Realtek |
| Chipset Model | RTL8111E |
| Number of Network (RJ-45) Ports | 2 |
| Media Type Supported | Twisted Pair |
| Total Number of Ports | 2 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
