Genuine Shuttle through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
DH02U3
Category
Barebone Systems
Overview
Powerful 1.3-litre PC with NVIDIA graphics supports four Ultra HD displays
This space-saving Slim PC integrates an energy-efficient Intel ULV processor and a dedicated NVIDIA GeForce GTX 1050 MXM graphics card which supports no less than four Ultra HD displays at 60 Hz frame rate via HDMI 2.0b. Its slim metal chassis with a VESA mount included, versatile connectivity and reliable operation in ambient temperatures of up to 50 °C degrees, make it ideal for professional applications such as Video Wall, Digital Signage, Kiosk, Surveillance and others.
Warranty
Limited Warranty: 3 Year
Highlights
Core i3 processor ensures timely and efficient performance for everyday computing needs
Upgrade an existing PC easily to improve performance and extend its usability for modern applications
Slim PC form factor simplifies usage and boosts efficiency, making setup and operation more convenient
7th Gen processor generation offers more threads and higher clocks for faster, optimized system performance
Can connect up to 6 USB peripherals for versatile and productive device integration
DDR4 SDRAM slot supports high-speed operation with low power use, delivering optimal performance and thermal efficiency
2.40 GHz processor speed provides efficient operation with dependable performance for everyday computing
Security Slot feature boosts productivity with dependable performance for demanding computing tasks
Specifications
Display & Graphics
Graphics Memory Capacity
4 GB
Graphics Memory Technology
GDDR5
Graphics Memory Accessibility
Dedicated
General Information
Manufacturer
Shuttle, Inc
Manufacturer Part Number
DH02U3
Brand Name
Shuttle
Product Line
XPC slim
Product Model
DH02U3
Product Name
XPC slim DH02U3 Barebone System
Product Type
Barebone System
Interfaces/Ports
HDMI (Rear)
Yes
Total Number of USB Ports
6
Memory
Maximum Memory Supported
32 GB
Memory Technology
DDR4 SDRAM
Total Number of Memory Slots
2
Physical Characteristics
Color Family
Black
Product Color
Black
Form Factor
Slim PC
Height
1.7"
Width
6.5"
Depth
7.5"
Weight (Approximate)
2.27 lb
Power Description
Input Voltage
120 V AC, 230 V AC
Processor
Processor Type
Core i3
Processor Generation
7th Gen
Processor Model
i3-7100U
Processor Speed
2.40 GHz
Warranty
Limited Warranty
3 Year
Miscellaneous
Package Contents
XPC slim DH02U3 Desktop Computer
Multi-language User Guide
Driver DVD for Windows 10 (64-bit)
VESA Mount for 75/100 mm standard (two metal brackets)
4 x Screws M3 x 7 mm (screws together VESA mount and PC)
4 x Screws M4 x 10 mm (to fix the VESA mount to the external surface)
4 x Screws M3 x 4 mm (to mount a 2.5" storage device into the bay)
2 x Screws M3 x 5 mm (silver colour, to mount two M.2 cards)
External 120 W Power Adapter with DC Cable
3-pin AC Power Cord with Protective-Earth Contacts, Cable Length: 1.7 m
