Genuine Schneider Electric through authorized distribution — NDAA §889 screened before checkout. TAA verified on request.
SKU
Category
General Purpose UPS
Overview
APC Back-UPS BX series are a quality range of products for price conscious customers, who wants a solution for, basic needs of power protection and backup for their devices at home and small offices which carry the brand promise of the largest UPS manufacturer in the world!
Warranty
Limited Warranty: 2 Year
Highlights
Experience higher efficiency with lower energy cost
Keep your sensitive devices powered with a backup of up to 1.36 minute at full load
1200 W load capacity - backup power for your valuable electronics
2000 VA load capacity provides sufficient backup during power failures
24V battery size for better reliance and optimal performance
9000 mAh battery capacity for convenient and prolonged usage to ensure maximum productivity
8 Hour typical battery recharge time to allow uninterrupted usage without requiring power outlet
Lead Acid battery chemistry delivers energy to the home/office through an easily controlled reaction
NEMA 5-20P plug/connector type for maximum usability with added reliability
NEMA 5-15R receptacle type offers maximum safety, convenience, and increased usability
Specifications
Battery Information
Battery Characteristics
Maintenance-free, Sealed
Battery Chemistry
Lead Acid
Battery Size
24V
Battery Capacity
9000 mAh
Backup/Run Time (Full Load)
1.36 Minute
Backup/Run Time (Half Load)
7.73 Minute
Battery Life
5 Year
Typical Battery Recharge Time
8 Hour
Controls/Indicators
Status Indicators
Power Button & Side Bar with Light Controlness
Display & Graphics
Display
LED
Environmental Conditions
Maximum Operating Elevation
9842.52 ft
Minimum Operating Temperature
32°F (0°C)
Maximum Operating Temperature
104°F (40°C)
Maximum Storage Elevation
9842.52 ft
Storage Temperature
5°F (-15°C) - 104°F (40°C)
Storage Relative Humidity
0% - 95%
Sound Emission (A-Weighted)
40 dB(A)
General Information
Manufacturer
Schneider Electric SA
Manufacturer Part Number
BX2000M-LM
Brand Name
APC by Schneider Electric
Product Line
Back-UPS
Product Series
BX
Product Name
Back-UPS BX 2000VA Tower UPS
Packaged Quantity
1
Product Type
Line-interactive UPS
Interfaces/Ports
USB (HID Compliant) Port
Yes
Physical Characteristics
Product Color
Black
Height
7.48"
Width
5.51"
Depth
15.35"
Form Factor
Tower
Weight (Approximate)
27.12 lb
Power Description
Load Capacity (VA)
2000 VA
Load Capacity (Watt)
1200 W
Input Voltage
120 V AC
Output Voltage
120 V AC
Input Frequency
60 Hz
Output Frequency
60 Hz
Waveform Type
Stepped Approximated Sine Wave
Surge Energy Rating
350 J
Technical Information
AVR
Yes
Plug/Connector Type
NEMA 5-20P
Receptacle Type
NEMA 5-15R
Receptacle Detail
6 x NEMA 5-15R
Dataline Protection
RJ-45
Cord Length
4.92 ft
Transfer Time
10 ms
Application/Usage
Home/Office, Modem, Router, Desktop Computer, Monitor, Television, Speaker, Surveillance System
Warranty
Limited Warranty
2 Year
Miscellaneous
Environmentally Friendly
Yes
Environmental Certification
EU RoHS
Environmental Compliance
Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
