Lenovo ThinkSystem RAID 9350-16i 4GB Flash PCIe 12Gb Internal Adapter
12Gb/s SAS - PCI Express 3.0 x8 - Plug-in Card - RAID Supported - 0, 1, 5, 6, 10, 50, 60, JBOD RAID Level - 4x SlimSAS x4 (SFF-8654) - 16 Total SAS Port(s) - 16 SAS Port(s) Internal - PC, Linux - 4 GB Flash Backed Cache
- SKU
- 4Y37A72486
- Category
- SCSI/RAID Controllers
$4,376.00
Back ordered — ships when restocked.
Genuine Lenovo through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- 4Y37A72486
- Category
- SCSI/RAID Controllers
Overview
The ThinkSystem RAID 9350 family of internal 12 Gbps SAS RAID controllers are high-performance low-cost RAID-on-chip (ROC) adapters that are designed and manufactured by Lenovo. These adapters support all major RAID levels including RAID-6 and RAID-60, and include support for Lenovo management tools.
Highlights
- PCIe 3.0 x8 host interface
- Two (8i adapter) or four (16i adapter) connectors to the drive backplanes
- Two adapter form factors: Low-profile PCIe adapter with broad server compatibility; Custom form-factor, designed to not consume a standard PCIe slot
- 12 Gbps SAS/SATA RAID controllers, based on the Adaptec SmartRAID 3152-8i and SmartRAID 3154-16i
- 2GB (8i) or 4GB (16i) of integrated flash-backed cache
- Connectivity for up to 8 (8i) or 16 (16i) internal SAS or SATA drives
- Support for intermixing SAS and SATA HDDs and SSDs. Mixing SAS and SATA drives in the same array is not supported. Mixing of HDDs and SSDs in the same array is not supported.
- Support for intermixing of 12 Gbps and 6 Gbps drives.
- Standard support for RAID 0, 1, 10, 5, 50, 6, 60, RAID 1 Triple, and RAID 10 Triple
- Support for JBOD (non-RAID, called "raw" or "HBA mode" in Adaptec parlance) drive state
Specifications
| Host Interface | PCI Express 3.0 x8 |
|---|---|
| Product Type | SAS Controller |
| Device Supported | Server |
| Manufacturer Part Number | 4Y37A72486 |
| Platform Supported | PC, Linux |
| Limited Warranty | 1 Year |
| Form Factor | Plug-in Card |
| Length | 6.6" |
| Manufacturer | Lenovo Group Limited |
| Product Model | 9350-16i |
| Product Name | ThinkSystem RAID 9350-16i 4GB Flash PCIe 12Gb Internal Adapter |
| RAID Levels | 0, 1, 5, 6, 10, 50, 60, JBOD |
| Controller Type | 12Gb/s SAS |
| Brand Name | Lenovo |
| Operating System Supported | Windows Server 2016, Windows Server 2019, Windows Server 2022, Red Hat Enterprise Linux 7.7, Red Hat Enterprise Linux 7.8, Red Hat Enterprise Linux 7.9, Red Hat Enterprise Linux 8.1, Red Hat Enterprise Linux 8.2, Red Hat Enterprise Linux 8.3, Red Hat Enterprise Linux 8.4, Red Hat Enterprise Linux 8.5, Red Hat Enterprise Linux 8.6, Red Hat Enterprise Linux 9.0, SUSE Linux Enterprise Server 12 SP3, SUSE Linux Enterprise Server 12 SP4, SUSE Linux Enterprise Server 12 SP5, SUSE Linux Enterprise Server 15 SP1, SUSE Linux Enterprise Server 15 SP2, SUSE Linux Enterprise Server 15 SP3, SUSE Linux Enterprise Server 15 SP4, Ubuntu 20.04 LTS, Ubuntu 22.04 LTS |
| Height | 2.5" |
| Environmentally Friendly | Yes |
| RAID Supported | Yes |
| Data Backup Type | Flash Backed Cache |
| Total Number of SAS Ports | 16 |
| Number of SAS Ports (Internal) | 16 |
| SAS Connector Details | 4x SlimSAS x4 (SFF-8654) |
| Cache Memory | 4 GB |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
