4 x Network (RJ-45) - 5 x USB - 328 ft Extended Range - PVC - Black
SKU
Category
Cable Extenders
$1,216.65
Back-ordered
Special order — estimated OEM lead time 3–8 weeks. Order today and we expect to receive stock between Oct 6 and Nov 10, then process your delivery right after.
Genuine Legrand through authorized distribution — NDAA §889 screened before checkout. TAA verified on request.
SKU
Category
Cable Extenders
Country of origin
China
Country of origin is manufacturer-reported and can vary by production lot. Where TAA applies to your purchase, we verify the shipping unit's origin on request.
Overview
The 4-Port USB 3.1 Over Cat6a Extender was designed to extend USB 3.1, 2.0 and 1.1 devices simultaneously up to 328 feet over a single Cat6a cable, making it a perfect solution for USB 3.1 conferencing cameras, interactive white boards, security and monitoring, video matrix systems, remote storage, and/or any other USB 3, 2 and 1 device.
Convenience
No software drivers required, making installation quick and easy with true plug and play convenience. Simply connect the Transmitter to the source computer, extend with a single category cable, and connect the Receiver to as many as four USB devices.
Performance
The 4-Port USB 3.1 Over Cat6a Extender provides the ability to connect USB 3.1 Gen 1 (5 Gbps) device types and is backwards compatible to USB 2.0 and 1.1 across a point-to-point connection. The extender also includes an Ethernet pass-through for connecting to network enabled devices or to use existing infrastructure without losing LAN connectivity.
Connector 1:
(1) USB 3.0 B Female, (2) RJ-45 Female
Connector 2:
(4) USB-A Female, (2) RJ-45 Female
Warranty
Limited Warranty: 2 Year
About Legrand
C2G, a brand of Legrand | AV, is an industry leading manufacturer of high performance cabling and connectivity solutions. Founded in 1984 as Cables To Go, C2G provides end-to-end connectivity solutions serving a variety of markets – including corporate, digital signage, education, healthcare, home theater, hospitality, and government.
Highlights
USB 3.1 Gen 1 data rate up to 5 Gbps
Integrated four port USB 3.1 hub
Supports all USB 3.1, 2.0, 1.1 devices simultaneously at full bandwidth
Up to 1.2A (6W) per USB port
100/1000 Mbps Ethernet channel
LAN pass-through
Point-to-point connection
Requires a single Cat6a cable
Plug and Play-no driver required
Specifications
General Information
Manufacturer
Legrand Group
Manufacturer Part Number
CG29523
Brand Name
C2G
Product Name
4-Port USB 3.1 Over Cat6a Extender
Product Type
Network Extender
Interfaces/Ports
Network (RJ-45)
Yes
Number of Network (RJ-45) Ports
4
USB
Yes
Number of USB Ports
5
Physical Characteristics
Color Family
Black
Product Color
Black
Product Material
PVC
Height
5.4"
Width
9.1"
Depth
1.3"
Power Description
Input Voltage
24 V DC
Technical Information
Maximum Extended Range
328 ft
Maximum Data Transfer Rate
640 MB/s
Warranty
Limited Warranty
2 Year
Miscellaneous
Country of Origin
China
TAA Compliant
No
Environmentally Friendly
Yes
Environmental Compliance
Restriction of Hazardous Substances (RoHS), Restriction of Hazardous Substances (RoHS) 2, Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
