Tripp Lite by Eaton USB-C to RJ45 Serial Rollover Cable (M/M) - Cisco Compatible 250 Kbps 6 ft. (1.8 m)
6 ft Serial/USB Data Transfer Cable for Modem, Router, Network Firewall, Switch, Computer, Notebook, Network Appliance - First End: 1 x USB Type C - Male - Second End: 1 x RJ-45 - Male - 250 kbit/s - Shielding - VW-1 - Black
- SKU
- U209-006-RJ45XC
- Category
- Connector Cables
MSRP$73.12
$31.80
Save 57%In stock: 172
Genuine Eaton through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- U209-006-RJ45XC
- Category
- Connector Cables
Overview
Connects Your Computer's USB-C Port to a Cisco Device
Directly connect the RJ45 console port on your Cisco modem, router, firewall, switch or other serial-based Cisco device to the USB-C port on your computer or laptop. The U209-006-RJ45XC supports data transfer rates up to 250 Kbps, as well as remote wake-up and power management. It is compatible with Windows, macOS and Linux. Filtering EMI/RFI Line Noise Helps Your Equipment Perform Better
This Cisco-compatible cable blocks disruptive EMI (electromagnetic interference) and RFI (radio frequency interference) line noise that can disturb your network equipment and inflict hardware damage or data loss. Premium double-shielding eliminates crosstalk and helps your connected components perform better and last longer.
Specifically Designed for Cisco Equipment
The serial cable is compatible with both older and current Cisco models. It requires no external power or additional adapters. You may download and install the necessary driver from the product page at tripplite.eaton.com/support (see the included owner's manual for directions).
Compatible with Eaton G4 PDU Network Card
The U209-006-RJ45XC can be used for out of band (OOB) management to connect the USB-C port on the G4 network card to an RS232 port on a console server.
Warranty
Limited Warranty: 3 Year
About Eaton
Eaton is an intelligent power management company dedicated to improving the quality of life and protecting the environment for people everywhere. We are guided by our commitment to do business right, to operate sustainably and to help our customers manage power ─ today and well into the future. By capitalizing on the global growth trends of electrification and digitalization, we're accelerating the planet's transition to renewable energy and helping to solve the world's most urgent power management challenges.
Highlights
- Connects your computer or laptop's USB-C port to a Cisco modem, router, firewall, switch or other serial-based Cisco device with an RJ45 console port
- Supports data transfer rates up to 250 Kbps
- Supports remote wake-up and power management
- Premium double-shielded cable eliminates crosstalk and reduces EMI/RFI interference
- Compatible with Windows, macOS and Linux operating systems
- Designed for Cisco equipment with no adapters or external power required
- 3-year limited warranty
Specifications
| Cable Length | 6 ft |
|---|---|
| Product Type | Data Transfer Cable |
| Data Transfer Rate | 250 kbit/s |
| Device Supported | Modem, Router, Network Firewall, Switch, Computer, Notebook, Network Appliance |
| Jacket Type | VW-1 |
| Manufacturer Part Number | U209-006-RJ45XC |
| Shielding | Yes |
| Limited Warranty | 3 Year |
| Weight (Approximate) | 0.24 lb |
| Features | Crosstalk Protection, EMI/RF Protection, Double Shielded |
| Manufacturer | Eaton Corporation |
| Product Model | U209-006-RJ45XC |
| Product Name | U209-006-RJ45XC USB-C to RJ45 Serial Rollover Cable, M/M, 6 ft. (1.8 m) |
| Brand Name | Tripp Lite series |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Cable Type | Serial/USB |
| Connector Type on First End | USB Type C - Male |
| Connector Type on Second End | RJ-45 - Male |
| Jacket Material | Polyvinyl Chloride (PVC) |
| Product Color | Black |
| Color Family | Black |
| Connector on First End Details | 1 x USB Type C - Male |
| Connector on Second End Details | 1 x RJ-45 - Male |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS), Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
