Tripp Lite by Eaton In-Row Cooler for Server Racks - 33,000 BTU (9.7 kW) 208/240V 42U

Get Highly Efficient, Reliable Cooling in a 42U Rack Form Factor

The harder your data center, network closet or server room works, the more it heats up, leading to inefficient operation, weakened performance and raised cooling costs. To help prevent equipment shutdowns, malfunctions and failures caused by overheating and temperature fluctuations, the SmartRack® SRCOOL33K provides a close-coupled cooling solution in a 42U rack form factor that reduces energy use, lowers operating costs and simplifies installation. Completely Self-Contained for Simplified and Less Expensive Installation and Maintenance

The zero-maintenance SRCOOL33K with its intuitive LCD interface is easy to install and operate. You and your IT staff can install it yourself. No costly startup service, electrician or HVAC contractor is needed. A built-in evaporator eliminates condensation through the exhaust air stream, so no costly floor drain, water collection tank, external condenser, refrigerant piping, ductwork or plumbing is required.

Advanced Network Monitoring Keeps You in Touch 24/7

The pre-installed Java-free HTML5-based WEBCARDLX interface enables full remote monitoring, configuration, control and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network.

Energy-Saving Features Meant to Save You Money

A row-based airflow path maximizes hot-aisle/cold-aisle efficiency and cooling predictability by delivering cold air high in the cold aisle and removing hot air in the hot aisle. The SRCOOL33K promotes temperature uniformity from 1U to 42U, allowing your equipment to perform at its peak and reduce power consumption and operating costs, and features an AC-driven rotary compressor.

One-Year Warranty and Environmentally Responsible Design

The SRCOOL33K comes with a one-year warranty. It's manufactured in compliance with strict RoHS specifications and uses eco-friendly R410a refrigerant.

More from the Manufacturer

Energy-Saving Row-Based Cooling Keeps IT Equipment Running Efficiently

Prevent equipment shutdowns, malfunctions and failures caused by overheating and temperature fluctuations. Tripp Lite’s 33,000 BTU 208/240V row-based air conditioning unit provides primary or supplemental cooling in server rooms, data centers and other locations with heat-sensitive equipment. A pre-installed LX Platform network card gives you Java-free HTML5-based remote management capabilities. Occupying the same footprint as a standard 42U rack, the SRCOOL33K is a close-coupled cooling solution that reduces energy use, lowers operating costs and simplifies installation.

33,000 BTU of Cooling Power

The SRCOOL33K has a cooling capacity of 33,000 BTU/h (9.7kW) and uses environmentally friendly R410A refrigerant to comply with worldwide standards. Its row-based airflow works to maximize the efficiency of a hot aisle/cold aisle configuration by delivering chilled air high in the cold aisle and taking in warm air from low in the hot aisle to promote top-to-bottom temperature uniformity. In addition to cooling, the SRCOOL33K filters and dehumidifies air to further enhance equipment performance.

No Water Collection Tank to Empty

With the SRCOOL33K, you won’t need an external condenser, refrigerant piping or professional maintenance. A built-in evaporator expels condensation through exhaust ducts, eliminating the need for a floor drain or water collection tank in most operating conditions. Simply connect the exhaust ducts to the building’s cooling system return in the drop ceiling plenum. The SRCOOL33K can also be ducted to the outside environment if necessary.

Made with Advanced Technology for IT Environments

The SRCOOL33K is built to meet the rigorous requirements of high-availability IT environments. This rack-width unit can act as a 1-to-1 replacement or a primary stand-alone computer room air conditioning unit. The unit has a soft-start feature to limit in-rush current, preventing line noise, voltage disruptions and potential circuit overloads that could be damaging to your data.

Cursus Sapien Ut

Convenient and Easy-to-Use LCD Controls

An intuitive menu-driven LCD control panel and diagnostic LEDs make on-site operation simple. With the touch of a button, you can power the unit on and off, toggle between energy saving and normal cooling modes, raise or lower the temperature in 1° increments and set the fan speed.

Built-In Advanced Remote Network Monitoring

The SRCOOL33K features a pre-installed Java-free WEBCARDLX network card that allows you to remotely monitor temperatures, change settings, define threshold warnings, receive alerts, access logs and automate operation via SNMP, Web, SSH or telnet.

Hassle-Free Installation

Installing the SRCOOL33K does not require disruptive construction projects or costly service calls from plumbers or HVAC specialists. It comes with everything necessary for standard installation and has a 10 ft. cord with a NEMA L6-30P plug for connection to a standard 30A 208/240V supply.

Environmentally Responsible Design

It’s manufactured in compliance with strict RoHS specifications, reflecting Tripp Lite’s commitment to environmental responsibility.
