Overview
40/100 GbE Cable Supports Higher Bandwidths Needed for High-Density Data Networking
As the amount of traffic in data networks grows, so does the need for devices and fiber cables to support higher bandwidths for high-density patching between data center MDFs and IDFs in enterprise installations. The N845A-05M-12TAA is a Type-A cable, which is ideal for straight-through fiber applications.
Recommended for 100 Gb Ethernet Applications
This multimode 50/125 cable is an ideal choice for 100G Ethernet applications up to 100 meters (328 feet) at 1300 nm. It is also backward compatible with 10 Gb, 25 Gb and 40 Gb networks, so you can future-proof your current application for an eventual upgrade to 400 Gb.
Aqua Jacket Helps Avoid Misidentification That Can Cause Costly Downtime
The OM4-rated cable has an aqua jacket to identify it as multimode in a crowded patch panel or switch and prevent it from becoming accidentally disconnected. The OFNP (Optical Fiber Non-Conductive Plenum) jacket is highly fire-resistant, making this cable ideal for plenum areas such as drop ceilings and raised floors. The connectors' slim boots allow easy one-handed installation and removal of the cable.
TAA-Compliant for GSA Schedule Purchases
The N845A-05M-12TAA is compliant with the Federal Trade Agreements Act (TAA), which makes it eligible for GSA (General Services Administration) Schedule and other federal procurement contracts.
Warranty
Limited Warranty: Lifetime
About Eaton
Eaton is an intelligent power management company dedicated to improving the quality of life and protecting the environment for people everywhere. We are guided by our commitment to do business right, to operate sustainably and to help our customers manage power ─ today and well into the future. By capitalizing on the global growth trends of electrification and digitalization, we're accelerating the planet's transition to renewable energy and helping to solve the world's most urgent power management challenges.
Highlights
OM4-rated cable recommended for 100 Gb speeds up to 100 meters (@ 1300 nm)
Type-A polarity ideal for straight through fiber applications
Backward compatible with 10/25/40 Gb networks to facilitate future-proofing
Aqua OFNP jacket allows easy ID in a crowded switch or patch panel
Compliant with the Federal Trade Agreements Act (TAA)
Specifications
General Information
Manufacturer
Eaton Corporation
Manufacturer Part Number
N845A-05M-12TAA
Brand Name
Tripp Lite series
Product Model
N845A-05M-12TAA
Product Name
N845A-05M-12TAA Fiber Optic Network Cable
Product Type
Network Cable
Physical Characteristics
Color Family
Green
Product Color
Aqua
Jacket Color
Aqua
Connector Color
Black, Aqua
Jacket Material
Polyvinyl Chloride (PVC)
Technical Information
Cable Type
Fiber Optic
Fiber Optic Mode
Multi-mode
Fiber Category
OM4
Fiber Count
12
Cable Length
16.40 ft
Connector Type on First End
MPO Network
Connector Gender on First End
Female
Connector on First End Details
1 x MPO Network - Female
Connector Type on Second End
MPO Network
Connector Gender on Second End
Female
Connector on Second End Details
1 x MPO Network - Female
Jacket Type
OFNP, Plenum
Device Supported
Network Device, Switch, Patch Panel
Data Transfer Rate
400 Gbit/s
Boot Type
Slim
Features
Fire Resistant
Warranty
Limited Warranty
Lifetime
Miscellaneous
Environmental Compliance
Restriction of Hazardous Substances (RoHS), Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
