Eaton Tripp Lite Series Dual-Monitor Thunderbolt 3 to HDMI Adapter (M/2xF) - 4K 60 Hz, 4:4:4, Silver
1 x Type C USB 3.1 Thunderbolt 3 Male - 2 x HDMI HDMI 2.0 Digital Audio/Video Female - 3840 x 2160 Supported - Nickel Connector - Silver, Gray
- SKU
- MTB3-002-HD
- Category
- Connector Adapters
MSRP$120.00
$81.82
Save 32%Back ordered — ships when restocked.
Genuine Eaton through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- MTB3-002-HD
- Category
- Connector Adapters
Overview
Thunderbolt Adapter Transmits Ultra HD 4K Video to 2 HDMI Monitors at the Same Time
This dual-monitor video adapter (M/2xF) connects the Thunderbolt 3 port on your computer, tablet, laptop, notebook or MacBook to two HDMI monitors simultaneously and delivers 4K video to both.
An Ideal Tool for Video Editing or Multitasking at Home or the Office
With this Thunderbolt 3 adapter's high bandwidth of 40 Gbps, you can more efficiently run applications that demand heavy resources. For instance, editing 4K video is easier with one monitor used for raw video playback and the other displaying your fresh cut. Home/office multitasking is more efficient with two monitors placed side by side on your workstation. And your video presentation or digital signage looks vivid and enticing in stunning 4K.
Enjoy the Clarity of 4K Video with Audio and 4:4:4 Color
This 4K HDMI adapter supports Ultra HD 4K video resolutions up to 3840 x 2160 at 60 Hz for crystal-clear picture and sound on two monitors simultaneously. The MTB3-002-HD is compatible with HDCP 2.2 content protection, 3D video and EDID. It also supports 4:4:4 chroma subsampling for top-level PC gaming or using your HDTV as a PC monitor, as well as 36-bit Deep Color (12 bits per channel).
Built-In Thunderbolt 3 Connector Attaches in Either Direction
Unlike traditional USB cables that connect in only one direction, the reversible male connector plugs into a Thunderbolt 3 port in either direction for a fumble-free connection every time. Thunderbolt 3 is eight times faster than USB 3.0 with four times the video bandwidth of HDMI. Note: This adapter only provides audio/video output when connected to a Thunderbolt 3 port. It will not function if connected to a USB-C port.
Ready to Use Right from the Package, So You Can Plug and Play Immediately
The plug-and-play adapter requires no software or external power. Just connect the built-in cable to the Thunderbolt 3 port on your source device, and use HDMI cables (sold separately) to connect the adapter to your display(s). Because the adapter is backward compatible with non-4K displays, you can use it with 1080p monitors or other available displays. Multi-resolution support ensures both connected displays will work at their highest resolution.
Warranty
Limited Warranty: 3 Year
About Eaton
Eaton is an intelligent power management company dedicated to improving the quality of life and protecting the environment for people everywhere. We are guided by our commitment to do business right, to operate sustainably and to help our customers manage power ─ today and well into the future. By capitalizing on the global growth trends of electrification and digitalization, we're accelerating the planet's transition to renewable energy and helping to solve the world's most urgent power management challenges.
Highlights
- Supports UHD resolutions up to 4K @ 60 Hz (4:4:4) for crystal-clear video
- Plug-and-play operation with no software required for easy, immediate installation
- Supports 36-bit Deep Color, 3D and HDCP specifications up to HDCP 2.2
- Reversible Thunderbolt 3 plug connects in either direction for instant no-fuss use
- Compatible with Windows 10, macOS 10.12 and lower versions
- 3-year limited warranty
Specifications
| Package Contents |
|
|---|---|
| Product Type | A/V Adapter |
| Manufacturer Part Number | MTB3-002-HD |
| Limited Warranty | 3 Year |
| Features | Extended Display Identification Data (EDID), HDCP 2.2, Plug and Play, Reversible, HDCP, HDCP 1.4 |
| Manufacturer | Eaton Corporation |
| Product Model | MTB3-002-HD |
| Product Name | Dual-Monitor Thunderbolt 3 to HDMI Adapter (M/2xF) - 4K 60 Hz, 4:4:4, Silver |
| Brand Name | Tripp Lite series |
| Country of Origin | Vietnam |
| Environmentally Friendly | Yes |
| Connector Type on First End | USB 3.1 Type C - Male |
| Connector Type on Second End | HDMI 2.0 Digital Audio/Video - Female |
| Maximum Resolution Supported | 3840 x 2160 |
| Adapter Type | HDMI/Thunderbolt 3 |
| Connector Plating | Nickel |
| Jacket Material | Polyvinyl Chloride (PVC) |
| Product Color | Silver, Gray |
| Color Family | Dual Color |
| Connector on First End Details | 1 x Type C USB 3.1 Thunderbolt 3 Male |
| Connector on Second End Details | 2 x HDMI HDMI 2.0 Digital Audio/Video Female |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
