Eaton Tripp Lite Series 2-Port HDMI Splitter - 8K 60 Hz, HDR10+, Multi-Resolution Support, TAA
60 Hz - 50 Hz to 60 Hz - 7680 x 4320 - 25 ft Maximum Operating Distance - Home Theater, Digital Signage, Notebook, Restaurant, Blu-ray Player, Monitor, Projector, Television, PC - 1 x HDMI In - 2 x HDMI Out - Box Mount, Wall Mount - Cold Rolled Steel, SECC - Black - TAA Compliant
- SKU
- B118-002-8K
- Category
- Signal Splitters/Amplifiers
MSRP$150.00
$97.82
Save 35%In stock: 37
Genuine Eaton through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
- SKU
- B118-002-8K
- Category
- Signal Splitters/Amplifiers
Overview
8K HDMI Splitter Transmits 8K Video + Audio to 2 HDMI Displays at the Same Time
Recommended for home theaters or short-distance digital signage applications in classrooms, offices, restaurants, bars, hotels and trade shows, this Ultra High Definition (UHD) HDMI splitter is quick and easy to install. It connects to an HDMI source device, such as a laptop or Blu-ray player, and transmits an 8K audio/video signal to two HDMI monitors, projectors or televisions simultaneously. Multi-resolution output allows video content to be presented at the optimal resolution for each display's capabilities.
Transmits 8K Video with HDR10+ and 4:4:4 Color
The B118-002-8K supports Ultra HD 8K resolutions up to 7680 x 4320 at 60 Hz with 36-bit Deep Color (12 bits per channel), as well as DTS-HD, Dolby TrueHD, Dolby Digital Plus and LPCM 7.1-channel surround sound. Place the splitter up to 10 feet from an HDMI source and up to 15 feet from a connected monitor for a maximum distance of nearly 25 feet from source to display. High Dynamic Range (HDR10+) provides a wide range of vibrant colors with richer contrast, brighter whites and deeper blacks that pop on your 8K display. HDCP 2.3 encryption allows you to stream 8K content with no loss in resolution. This splitter also supports uncompressed 4:4:4 chroma subsampling for top-level PC gaming or for using your HDTV as a PC monitor.
Multi-Resolution Support Allows Mixing and Matching of Displays of Different Resolutions
Say you have a brand new 8K/60 Hz HDTV in the living room, but want to also connect your Blu-ray player or media server to the older 1080p TV in the kitchen and the 4K/60 Hz monitor in your home office. The B118-002-8K is backward compatible with 4K and 1080p resolutions via automatic switching, allowing each connected display to show video at its maximum resolution without affecting the other outputs.
Ready to Use Right Out of the Package
The plug-and-play HDMI splitter requires no software to download and install. User-supplied HDMI cables (such as P568-Series, sold separately) connect the splitter to both the source and displays. The included external power supply comes with four international plug adapters that allow you to use the B118-002-8K around the world.
Warranty
Limited Warranty: 1 Year
About Eaton
Eaton is an intelligent power management company dedicated to improving the quality of life and protecting the environment for people everywhere. We are guided by our commitment to do business right, to operate sustainably and to help our customers manage power ─ today and well into the future. By capitalizing on the global growth trends of electrification and digitalization, we're accelerating the planet's transition to renewable energy and helping to solve the world's most urgent power management challenges.
Highlights
- Supports UHD resolutions up to 8K @ 60 Hz (4:4:4) with High Dynamic Range (HDR10+)
- Multi-resolution function allows combination of different display resolutions at once
- Includes 4 international plug adapters to allow use of the splitter around the world
- Plug-and-play operation: no software required means easy, immediate installation
Specifications
| Application/Usage | Home Theater, Digital Signage, Notebook, Restaurant, Blu-ray Player, Monitor, Projector, Television, PC |
|---|---|
| Package Contents |
|
| Product Type | HDMI Splitter |
| Input Voltage | 100 V, 240 V AC |
| Manufacturer Part Number | B118-002-8K |
| Limited Warranty | 1 Year |
| Weight (Approximate) | 1.54 lb |
| Form Factor | Box Mount, Wall Mount |
| Manufacturer | Eaton Corporation |
| Product Model | B118-002-8K |
| Product Name | 2-Port HDMI Splitter - 8K 60 Hz, HDR10+, Multi-Resolution Support, TAA |
| Brand Name | Tripp Lite series |
| Country of Origin | Taiwan |
| Height | 1" |
| Width | 2.5" |
| Depth | 3.6" |
| Maximum Frequency | 60 Hz |
| Minimum Frequency | 50 Hz |
| Maximum Video Resolution | 7680 x 4320 |
| Maximum Operating Distance | 25 ft |
| Number of HDMI Inputs | 1 |
| Number of HDMI Outputs | 2 |
| HDMI In | Yes |
| HDMI Out | Yes |
| TAA Compliant | Yes |
| Product Color | Black |
| Product Material | Cold Rolled Steel, SECC |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS), Waste Electrical and Electronic Equipment Directive (WEEE) |
