Comprehensive Cat 6 550 MHz Shielded Solid Blue Bulk Cable 1000ft
Comprehensive Connectivity

Comprehensive Cat 6 550 MHz Shielded Solid Blue Bulk Cable 1000ft

1000 ft Category 6 Network Cable for Network Device - First End: Bare Wire - Second End: Bare Wire - 3.2 Gbit/s - Shielding - CMR, CM, MP, Plenum - 24 AWG - Blue

SKU
CAT6SHBLU-1000
Category
Connector Cables

MSRP$561.99

$493.96

Save 12%
Back ordered

Back ordered — ships when restocked.

Get a quote

Genuine Comprehensive Connectivity through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.

SKU
CAT6SHBLU-1000
Category
Connector Cables

Overview

Category 6 550MHz local area network cable. 4 shielded twisted pairs, solid 24 awg. Supports all category 6 applications including Ethernet 100BASE -TX, 100BASE-VG and 155 ATM. Particularly suited for high bandwidth applications such as 622 ATM, Wideband, Ethernet 1000BASE-T and emerging applications with anticipated data rates to 3.2 Gbps. UL listing NEC,CM/MP. Nominal O.D. is 0.26 inches. Meets all requirements as set forth in the Telecommunications Industry Association's standard 568 & 570 recommendations. Foot-marked cable is packaged in a pull box for easier installation.

Highlights

  • High-Performance Data Communications Cable for Noisy Environments
  • Suitable for 550MHz High-Speed Data Applications, Gigabit Ethernet, Fast Ethernet and 155Mbps TP-PMD/CDDI
  • Category-6 Shielded Twisted Pair (FTP) Cable
  • 4-Pair - Easily Identified Color-Striped Pairs
  • 24AWG Solid Bare Copper Conductors
  • Excellent Attenuation and Crosstalk Characteristics
  • Exceeds EIA/TIA 568 B.2-1, UL, CSA and ISO/IEC 11801 specifi cations
  • UL/cUL or ETL Listed
  • Sequential foot markers

Specifications

Cable Length1000 ft
Product TypeNetwork Cable
Data Transfer Rate3.2 Gbit/s
Device SupportedNetwork Device
Jacket TypeCMR, CM, MP, Plenum
Manufacturer Part NumberCAT6SHBLU-1000
ShieldingYes
Limited WarrantyLifetime
Weight (Approximate)27 lb
FeaturesStranded
ManufacturerComprehensive Connectivity Company
Product NameCat 6 550 MHz Shielded Solid Blue Bulk Cable 1000ft
Package TypeBulk
Brand NameComprehensive
Country of OriginChina
Environmentally FriendlyYes
Cable TypeCategory 6
Connector Type on First EndBare Wire
Connector Type on Second EndBare Wire
American Wire Gauge24 AWG
Jacket MaterialPolyvinyl Chloride (PVC)
Product ColorBlue
Color FamilyBlue
Connector on First End DetailsBare Wire
Connector on Second End DetailsBare Wire
Jacket ColorBlue
Number of Pairs4.0
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
