Club 3D Mini DisplayPort 1.2 to HDMI 2.0 UHD Active Adapter
5.91" HDMI/Mini DisplayPort A/V Cable for Audio/Video Device, Gaming Computer, Notebook, TV, Monitor, Projector - First End: 1 x Mini DisplayPort 1.2 Digital Audio/Video - Male - Second End: 1 x HDMI 2.0 Digital Audio/Video - Female - 18 Gbit/s - Supports up to 4096 x 2160 - Black
Genuine Club 3D through authorized distribution — TAA country-of-origin verified and NDAA §889 screened before checkout.
SKU
CAC-2170
Category
Connector Cables
Overview
CAC-2170 - The Club 3Dis an active HDMI 2.0 signal converter. The Mini DisplayPort 1.2 to HDMI 2.0 UHD Active Adapter is the easiest solution for connecting your Mini DisplayPort 1.2 Game PC or Laptop to an HDMI enabled 4K UHD Television, monitor or Projector. The adapter is compliant to HDMI?2.0 specification allowing for 6Gbps TMD Sthroughput per channel. The interface in the adapter has three lanes for HDMI data, clock, HPD signal and power, offering a total TMDS throughput of 18Gbps.
Supports up to 4K UHD Resolution at 60Hz.
The Mini DisplayPort 1.2 to HDMI 2.0 UHD Active Adapter supports UHD resolutions of up to 4K UHD 4096x 2160p @ 60Hz for a clear, sharp picture. The support for 60 frames per second provides exceptionally smooth video or gameplay. Use the adapter to play games, view video or browse the internet from your MiniDisplayPort 1.2 enabled device in Ultra High Resolution. Supporting up to 8 channels of audio, the adapter provides Ultra High Definition digital audio and video. It is the ideal solution for anyone who wants to enjoy 4K UHD/ 60 gameplay but lacks a native HDMI 2.0 output in their system configuration.
Highlights
Compliant to DisplayPort Specification 1.2 for 1.62Gbps,2.7Gbps and 5.4Gbps per lane. Effective (video) bandwidth 17.28Gbps
Compliant to HDMI 2.0 Specification, data rate up to 6Gbps per channel total throughput 18Gbps
Supports full link training and no link training
Repeater for HDCP 1.3 and HDCP 2.2
Supports 24-bit color and 4:4:4 color sampling
Internal YCbCr 4:4:4 /4:2:2 to YCbCr 4:2:0 conversion capability
Supports UHD resolutions up to 4096 x 2160p @ 60Hz and 1080p 3D
Supports AMD GCN cards, Nvidia® Maxwell cards and Intel® HD 5XXX series and newer. Not intended for older architectures.
Specifications
General Information
Manufacturer
Club 3D
Manufacturer Part Number
CAC-2170
Brand Name
Club 3D
Product Name
Mini DisplayPort 1.2 to HDMI 2.0 UHD Active Adapter
Product Type
A/V Cable
Physical Characteristics
Product Color
Black
Weight (Approximate)
0.12 lb
Technical Information
Cable Type
HDMI/Mini DisplayPort
Cable Length
5.91"
Connector Type on First End
Mini DisplayPort 1.2 Digital Audio/Video - Male
Connector on First End Details
1 x Mini DisplayPort 1.2 Digital Audio/Video - Male
